happy holidays everybody! :-)

Hello all! :-)

I needed a horizontal and centered panning button/slider. I am completely new to HISE and didn't find a built in solution so I scripted it myself. Please feel free to use the code if you need it. :-)

All the best
Oli / www.studiobro.net

HISE Snippet:

HiseSnippet 1692.3oc0X0saaaCEVJIpq1caXcnEaWrK3L1ExcINVtsIEHanwwNt0nw+fX2zBLLTPKQayFIRAIpj3Nzmsc6ta6QXOB6MX6PJKaoF2rLm1NTi7GO+wOdNGdNGltAbaRXHOPSOW+I9DM8O0n2DlXbswXJSqYcM8uw3HRffZicQcwLFI.0mDJPkqrQ4JZ6MwGGFRbzz0W8QRMzysll5ye8v8vtXlMYNIMsi3TaxATOpXN0t69DpqaCrCoO0Kkz2a2l1bVMtKOBP2pFk07w1GiGQZikhshgl9012gJ3A8DXAITSes83NS5MleJKV9ingzAtD4BKsdfghI2f65HQrjpVswTWmtIdgPMMcity8IqF6StkQKpCcF849luPw.MWiz9C8UxBuUy.OqzvqbJ3s.HomBRqECoaZzyNf5KlyQhmaXzjIHACwfaOMThkUake+ZF03fDLQIO7wjFAvhYZXtU4xqifeTbm7atYrJnASPsJg53ROAB7O000CRA.tmd5okBEQNT9f.dIFQ.zZDPHHAGEER917427Na.epuesCpdX09M6zt2FWgO2YSXCpEP.OI5.tLW7.N+XTUlCpAg3h5L3kDaQdHgARMOlwGnX+injSqsRUklRNfdR0LKletYk1pIy1MxgfdBXAEgdDwh2oDCicbjBaVP9SqBqipHchUTNwXzbBNPYOqTvYDQTi64yYvhDUAET+QoPh3b.M4HABAHNAlOCeBYHOvC8HBbuDC4Zo1yDly3IAf5tsZ6kIYpUlENuYTnA1nivATLjiFlWZQeL6HraDwZmrK6S77iI4RYjmCaS4cRR.dR6N6g5se+9Ma+ndWo3+LmSKtCwr.TKJiKqmXhKP9w7.5q.uL1MCWyBdTFDc1vpT42fN9Lf94HGJH98nuh.7JWprUwrGntUa1tOpwSaWSlYujGnjXZo.xHJreAMhX1BJmYVvI.e5AfuDGzyk5PB.TLLg4n0Q7AurX9eIetM2rNw1EG.IuPNLJIZkOmLVfg3.HXIfMdm74PvWvcTnTab18dPwzQA7HlCvXTog.ipttlw0aCKMvE3Wbld0vt1QtxqIJkkXCU3rBytiH6LPYi.YoCMiciPRlJ8vrH5GfLhh.O.xnbyRa.7cNIuCxbCK01lKS5EHKDhPajJGTBrbIIblYkdSTEosrp7.kojeCUzxfybm+9gLxWUHBnChDDSq0OG7T.60v2D2PR74YFB15dnuGYVtD7a3PrfClETSPZ..MuIXtRXQEepCILyCMpHZnrFiLXNKld5XpfnzaTojLLSE9WGM8WPsK7Oc2eFtPTVci.L+qKtSRtGhyZyEjNLSU5W9WmG8lrFNbg7jE9B3ttjfExV14O3hTzjE4MfDrNTYCN8yDDZGlsGqwauGa5Q.riqCmRPNqIiJ53SXusACzlV7V1OdJp.QEptwe9ztww2V0nPS2OwPEwzT.N8LPZOsYcr.mXFvhvt3KGwRd.zqSNAlQJtIeNi5jviEbekrS6W.c4+W2zy.Og9uA60jj+HTVdTNc27BjZdTGGWRWdHU5rSiQuLSx8qgQCGROS5XNPyCp9BF0.Rd0BA+mJcrK2OxWt8UGvOgnIHmIRFbKug0Vau81UrtOLp24FiAFfh6HKrjcpJ4njSYHQV5QYjiqv.DOI8nluyF05xBwaZzkJrGuXLtxBvHDteefwoCn9YF6ObHLVxb.tlQim+9YZzza+si29aXHKfollPs421XAiTbAuU3OtruUv+R+VgN1B.B8CvrPedHwJskeCdURyqNQDwxJdLoLRIOdMfiWJ4t9tIDqjlHbMIiwf0YrTK48pjk+4C2mIaf2i.mFmNg1vgU56Rmp2MB587LpiXrUZEmStRZxOFGHmxyNSh3pWzylrVxmMcs2WOaZsKWh5ECuOBJ8j4Ud4RvXOpmuKYe1IDWnIgBieIzUXHNxUjPM6UqVbF2eLmQyDzOj.yRLZDIStzBOPvTGvneyobqcOj3Rvgott8c6FObZKUufkxWX8e9EuKLd80FwvEIqGftJwsOnoYWX6iUuTsOdmi2kuUxG3anPIyOdhzekATFuBREtQ++GuOjGIfmbzBCUCjCI1NxqGzyzl.Hlwfm0HmWbE4vtwqKKWKgSOByQs3ugOSYZIWqOkoUByOH6gG1Nf+B63wvkELtthBbtYp+6f4LZIWilM+sgA7fF4DuzWXaKyo2.7OKVmJKgN2cIz4dKgN2eIzYqkPmsWBcdvEpirie0HA2KN+GHzce06fz0iG5QcUP6e.wSHwv

Hello everyone,

For a project, I need a 3D cube that rotates. I asked chatGPT if it could help me, and it actually worked! :-)

I'll post the code here in case anyone wants to play around with it.

I'm still bothered by the fact that the cube changes size and “pumps” when it rotates. I still need to take care of that. Or does anyone here have any ideas? :-)

Have fun trying it out and with matrix multiplication. :-)

I have translated the comments into English for you.

All the best from Germany,
Oli

HiseSnippet 2102.3ocsXzlaaibkxIJsVc21t.8.Lv+nfxlRQTV9q0caW+gbhPicDrbbiqgvhQjiDmZJNDbFYIk1Tz6POM85zSPuAsu2LjTT1JYyZfJaQQ99ddeMyicSDdLoTjXUpxUyiYVk9px8lGoBNIfxir5bpUoeY4yoREKgX.c77XpTx7sJU5YuBATZ8mao+7e9CGSCoQdrEfrrtVv8XugOlqV.s62+G4ggmQ8YWwGWf5VeeGOQzIhPwDvddV4FVwTu6niXWPQxVqr0qox.qRaV1c2lC2ys0.3uCZtaK5fg62XeW2CNfxNXHqoeqc81m1nUCqRunsOWIR5onJlDD5wB+48BDSiLJ3ZtjOHjgO3Z0CzrAr0IA7P+tYNGokUom2cgq5YFW0uo74bedN7EtresFAYAGEcZkV6yYRt+DLoRELomaLouobOuDdrZAFzd9Ek6DAQvgTH1TzTLzZs1+5qJeh.nHRUeL8N1YIvC4bXuaiFND3R0CqT4kujTqVMxkBv34QiHaeJwax.FgGQdcmdsQjYzbzDUfH4aIdAT0q5dEYJWEPnjPtRExHArvXxvDwX.jjONFAMYLMhLfgxEkCJH62Fq3hHZnCYnHgHCnIwPpXHOhIIBPo7S61oZkLqWxTuSxdMeTvkLoHbBx6YhjtzHVnzVkLgktH7RXf2mDiHp.IcRE4dJjhCqEMwjuijISpuuFj8F4X2vg31.+BRKGHpb6Mlx8UA.9s2eEHCXfko9TXogghom.WG.Y8RfpMNJLjr.Ppo2idOijnC.fCPhYQn62rTVHRephVmFMJj8dXwzndiCIDBv9kYbNYL48qj9a9jzeyCoWFyX9ox2cmCKRubDS5ELkG4yGcGiqVIqoppYiCeHZLBeU.26NHPKApbquiY4iz8sj8I2yRTPqEIwl4OhQBYQif7qlNDOFl4RhE7HEwtgC7W0pEhwW29xq5AR71JqeaMWG8+8cH2RV9dR180VbOn9.NlUjyJo.qjBrRJvJbu1SduHIhUouYYzFLZv1oRH14ylAgOdBduw7JZusO8Usyr2FNfbu00oIbsoy1v0scZ7.CqkyN.7cb1Ettqydv08bZYnwXAnXZoEyNZwrqVL6YLxdPnBDSpUhUofub3jHOcLsBOBCL4.v7v2ei88ND5L367pU9qUVG3aVdBZk0CEdzPh2LXIbNUET2SHsoyfj4TLxbLRdzRXPD2eai94.lqA31eSPZ0f6Z1eS4rbreHCKHwsLX8.rZCZ9iMn4KYPyKXPyWxfJfYVS.CY1l.uaQ9vlx4KzMho1L.jFi2bTuIL0jjHxsyfrx4N.MvJ4iZ+ZWVBj+CtPnTNNQ7WXFuYseO4h2d44G8lN+41mZpnIdBQhOOB2q.xlqW2s5iBBoR3JwEhjw1wa6Pl5PBbHRvxXYgjSf8PSnDwvgPyFrY5TZhOQJHJn+LIRnBv9tbIz.FtyG.yHdZdJ5ei2FbqvRrETNRx+.heCCsDeNzQBNCvFYbMD3RaHjWR9PAdzbcl35ZHRP0YzGiQc6ojMgFC6TETEnxF82bnt4RLeFzjKiRLNYGjQYMjR2knjXeCQIHShqtHX.x+kn+A3Fxu6eXtsLFbdfk7AludqF+D5ztPRfc0rXFr6t5RArmRDz.53IvtwjeqlL81QP3RErbK8hbXmEsrGoiHXk8Tv9A2tr9Hl5Og6aXioZHlfBXdsdSibTxrjywPxIFmqBN.WrcMXiBnqHreAIympi7cSXwzjz8LfUmtynzHM5rLMUX+hTMQm+Xb2f40HxKuFaI0eQKePvXKYPtn2yFogic2OD942Y5pU2zjFfr0VPDY8Kutd7DYfsoIhlja48y6kTMs103py8wD6nEQpBUGUMFlljE6da1n2DHQ4kabLiww.iS2gM23XZiCBQFm.P1kWeqljaY8gTQrcjF0fGfxEQkh6Hrevx0kz7xxpYR33GS0fhTAjEq6ConIpKXS6MYfdkbTyawt9vOt80BSSkdKSg8wFjGmg7iFuXuPLMJbNwmlbGKRWeimqXThXBTtaKROnEr1GgIuligaa9QVGO81QgwAzbHCBAtcfZul6fgJfqgvo5uDVJ1YotuAqSOFkuztQd7TWxfmZ7KUSSCf8jPMcPphxqMw0sCY0pyoPt6Rml.jwGSOKktTsFNEBbP0NQXxhjQzY5PscBCUzx0zZZyNS1hhZcM8pO70VeGYkmZ5vUyvMeJFtYIFvZZnL1tvh4uucCxYc6AM8DSfV2PHlAGgvc2+8+3e1pwXo9QVzglEMQuPv98uqSsAvp1ud0hqTLiSSh81aW8v7sZDQWHTr2ltfgNijGhZ3vUhCqGSDggf.WEZip9LLZGMY7.VhCbjnvIrbBgAeVdZpW7kMMkmo8PABEQch3p2FyRe9LQnONkDd+im8xJs+Bb265bJDivwwRgAzEiGNEMmRmxtGNkpY3r0KeJSdmRDqocbrHBkPoelRi8qyFcCC.Vbebrs7.h0LqRkKUAT27razSZ.B8E+sRlwmMSWTDxxSTXU5WUdoIJfIwez.jvnqB+IgT0xyyhS5mh.BKKMDINnXjjqlW7MA7SXH2Fe1gb+RMwuobWtxKX013ZqvFg.1+OrwzWMvWWt8vgPqvEF3yKe16epuGfeD0aNhwH3TAIbLO4hIi6AMN8Xf1ivIewTl0vjVyyMvmQOPOVju9g+K7IEoK9boTjtYHsFS8RD+fmoXDe4C+bMDvlhzubl0KeN9Lw0RWfVzOOl6y+AOukE0iXr4SkwsepL15ox3NOUF28ox3dOUF2+GmQ7UUczDkXrorwx57ts0czJUpcDEx.0YqV+O.znjCC

Some of us would like to disable the “Skipping changed() callback during onInit for...” message.

To do this, please open the document “ScriptingApiContent.cpp” and comment out the following lines before compiling HISE:

if (!parent->asyncFunctionsAllowed())
{
    debugToConsole(dynamic_cast<Processor*>(getScriptProcessor()), “Skipping changed() callback during onInit for ” + getId());
    return;
}

Just like in HISE, you also comment out code in C++ with this:

//

All the best
Oli

Ok, it can be solved quite easily with a broadcaster. You should also query whether a preset is loaded so that the browser does not close if you simply double-click.

For anyone interested, here is a snippet:

HiseSnippet 1303.3ocsW0raabCDlqr2jJ01zFf9.rPmjKDTjrrSTaPQskrbqPiRDrbSSQPP.WtTRDdWxEjb8OHv.8Pe.549Vz2rdqGSGRtRZksZ9Q.UGR14+ONblgiGIEDpRIjHuJmdUJE48Y9iuhqm0aFlwQCNB4cO+gXklJCbr5dUJVonQHOus9ACCuxair+96uuKNFyIzkrPnmKXD5SXIL8RtiN3mXwwGiinmxRJn8dGLfH38DwhL.Oa42DkhImgmReJ1nVIezOhUyPdeseaZztc5f2eu1sIc9lNjGQvcnjVgOp4t3IQs6PiBi1a+8vHu6zOhoExwZrlp.m1UDc03YhK3t.7blhEFSMDsPigH6Xi5MiEGMZdxQgPdaOZYpZKWp5q7GxhXK3uLk8kVAAKsnXRyqz6BRs9HfjWAHssCR22eLQxR0KkXvym5OfC2fSvvcSQn3zEU5ta42S.Zv0MRvmQOVBDKrn1Ca1rd.7O673JUf6GkN3brLHML36Bla0TptmHIUvAhZUSCqZz8AOHnqTfiHtxmH5DFmoYBdAuDR.uzmOkwoMHRJjQJXRs2TIHnJKp52FTMjTstgBKmp.5WVkLOdUqGTkdt4iWY0PicZ7pJWmiBrViIyBzh.qdAlTUkPRCG+SEKf9PQlh12nip1KMGiWA99v33fd333PnVTYBV0Uc6DlDNLwL.wbpz52nnmjSVKMDr.7T8fIYbh4zWaAxq6vyNuoRY1jZ1uaDIxfK+dwLxY6Tob4zvFJnzvjmkh3ZSvwJJD94mrmkR4PYFUQ0lb8EJ..LdLjMWDt.AOTyMJN2IEh+433L5NUb.Hm3VAUKyrwDB45uuy8e0cZnL7sVMOiU6lgG7TAn8Tgl9LdMKDpbckfaJZxj0JK2WwPBdchMiUjuKCqwyRBoxhI.ihPazp8l24Cq2j3RKETTvG.05lisi9XQbjomy78s6jQ44U3qedvQXM1zbmyCzKkJ0LCb7NhdNLN00pW1+Hp5LsHElLt3x.5004ylbM2GGKvZFe5oL.1L.Aa6mFhtbwP2e64Gb0xIv+5A4Q0Ehuv2UakWZgBmNe3b46.Z+OFSXZZxRt+0a+i2tJ2cyU19yd1J86k7sc1l70X74ztYZsfC8rlJs5ykz+xTLWAWapCUfqxRLZXa.VnhMqJWu4lxG0s7Ib65TeEQKYCEbv4Ej0p4BiNLJZ8g3DJGdXZ8xNhFS0+GxNFetPBYHyqcEkkirAvoNh1UHgy1JG4mlk3RDFv21xxQ+KrH8rSf6YgYvGvOHnYi123W8OR9.a2.UyrrCgYyKxM4Qn959uEV4P1IhKFAiCgBvOT6FSwRxrtXYWQFOxMI2JXnPlmOuojk0P2Tx7L8sjV4ZzEljFxy26O8PnYT1zYZC0od19wE8S200Ocu79ImmrcRk8ymrUrcJoX6ziOPSuTaL1NnddajBv6.tq0x7LLSMTj.ACKAa8Jgt8y5vBEhnrXrd0sLL6ekK.5SV4ocyy2Pcj9ph6m8Qr5Qy24pGenP799iXZxr0iwRqAivfu+OvX9Baete+ISnD8R.ts+wuXS2N68D9SDYlAuCwZICJP7gt2wv7PBEhNmSiUlpsRlhMGcSCsICLlxirDuE9kKrkg1KWXq4BQIXhT7Zh6QMyJgehkCfItck4xvt6.cPKj8gth44DXC0WSHq5paY3tapgs2TC2aSMb+M0vGtoF9nM0vNueCM+ADGloEIt1FDZ3n91WO875ywPEnsZE8u.cyl5YA

@d-healey
Thank you, that worked.
For the “UI” example, the code is as follows:

Content.getAllComponents(“^(?!.*UI).*$”);

@Straticah
I am referring to the general amplitude ADSR. I took a look at the C++ code. If I remember correctly, the parameters Attack and Release are present, they are just not made available to the user via a slider. I am currently finalizing a plug-in and therefore do not want to experiment with the HISE C++ code. However, when my plug-in is finished, I will try to implement the sliders myself. If I succeed, I will be happy to let you know. :-)

@rglides
@Mickolos

@d-healey has already said it all. :-)

In addition to “getAllComponents”, the following should be said: This function uses regex to select the corresponding components. It therefore makes sense to familiarize yourself with it.

With const comps = Content.getAllComponents("^.*(Knob|Button).*$"); you can, for example, select all components whose name contains "Knob" or “Button”.

With const comps = Content.getAllComponents("^(?!.*Slider).*(Knob|Button).*$"); you can select all components whose name contains “Knob” or "Button", but not “Slider”.

And with const comps = Content.getAllComponents("^(?!.*Slider).*$"); for example, you can select all components except those that have “Slider” in their name.

@d-healey Thank you for uploading the video! :-)

@ustk
I have found the problem. I had linked a button. This button appeared in the component list before the button to which it was linked. Of course this cannot work. :-) I removed the link and now everything works.

@Goodflow
That's right. But how do you get the information about which modulation mode was selected? In other words, whether “scaled,” “unipolar,” or “bipolar” was selected?

Perhaps via “modulationMatrix.getMatrixModulationProperties” or “modulationMatrix.getComponent,” or you could use “modulationMatrix.setConnectionCallback” and then write the information to a variable.

@scottmire
I have never used Claude, but I have heard that it is supposed to be better in terms of coding. However, I am uncertain whether this also applies to the new GPT5 version.

@d-healey
Yes, sometimes it works well. But sometimes it doesn't. There are always little mistakes. For example, “var” variables are created in functions instead of “local” variables every time.

But chatGPT often helps you get on the right track.
For example, chatGPT has often helped me calculate mathematical formulas for LAF functions.

It's quite an impressive little piece of technology! :-)

@scottmire
Of course! :-)

Since I'm from Germany, the original prompt was in German. However, the translation is quite simple:

"Please use the HISE scripting language to draw me a 3D grid of a rotating cube."

But don't be fooled—chatGPT is in no way reliable when it comes to generating code! Today, I used the same prompt to generate a cube that doesn't change in size, and chatGPT failed completely. It didn't even manage to reproduce the same result. Creating a working script with chatGPT is pure luck.

Hello everyone,

For a project, I need a 3D cube that rotates. I asked chatGPT if it could help me, and it actually worked! :-)

I'll post the code here in case anyone wants to play around with it.

I'm still bothered by the fact that the cube changes size and “pumps” when it rotates. I still need to take care of that. Or does anyone here have any ideas? :-)

Have fun trying it out and with matrix multiplication. :-)

I have translated the comments into English for you.

All the best from Germany,
Oli

HiseSnippet 2102.3ocsXzlaaibkxIJsVc21t.8.Lv+nfxlRQTV9q0caW+gbhPicDrbbiqgvhQjiDmZJNDbFYIk1Tz6POM85zSPuAsu2LjTT1JYyZfJaQQ99ddeMyicSDdLoTjXUpxUyiYVk9px8lGoBNIfxir5bpUoeY4yoREKgX.c77XpTx7sJU5YuBATZ8mao+7e9CGSCoQdrEfrrtVv8XugOlqV.s62+G4ggmQ8YWwGWf5VeeGOQzIhPwDvddV4FVwTu6niXWPQxVqr0qox.qRaV1c2lC2ys0.3uCZtaK5fg62XeW2CNfxNXHqoeqc81m1nUCqRunsOWIR5onJlDD5wB+48BDSiLJ3ZtjOHjgO3Z0CzrAr0IA7P+tYNGokUom2cgq5YFW0uo74bedN7EtresFAYAGEcZkV6yYRt+DLoRELomaLouobOuDdrZAFzd9Ek6DAQvgTH1TzTLzZs1+5qJeh.nHRUeL8N1YIvC4bXuaiFND3R0CqT4kujTqVMxkBv34QiHaeJwax.FgGQdcmdsQjYzbzDUfH4aIdAT0q5dEYJWEPnjPtRExHArvXxvDwX.jjONFAMYLMhLfgxEkCJH62Fq3hHZnCYnHgHCnIwPpXHOhIIBPo7S61oZkLqWxTuSxdMeTvkLoHbBx6YhjtzHVnzVkLgktH7RXf2mDiHp.IcRE4dJjhCqEMwjuijISpuuFj8F4X2vg31.+BRKGHpb6Mlx8UA.9s2eEHCXfko9TXogghom.WG.Y8RfpMNJLjr.Ppo2idOijnC.fCPhYQn62rTVHRephVmFMJj8dXwzndiCIDBv9kYbNYL48qj9a9jzeyCoWFyX9ox2cmCKRubDS5ELkG4yGcGiqVIqoppYiCeHZLBeU.26NHPKApbquiY4iz8sj8I2yRTPqEIwl4OhQBYQif7qlNDOFl4RhE7HEwtgC7W0pEhwW29xq5AR71JqeaMWG8+8cH2RV9dR180VbOn9.NlUjyJo.qjBrRJvJbu1SduHIhUouYYzFLZv1oRH14ylAgOdBduw7JZusO8Usyr2FNfbu00oIbsoy1v0scZ7.CqkyN.7cb1Ettqydv08bZYnwXAnXZoEyNZwrqVL6YLxdPnBDSpUhUofub3jHOcLsBOBCL4.v7v2ei88ND5L367pU9qUVG3aVdBZk0CEdzPh2LXIbNUET2SHsoyfj4TLxbLRdzRXPD2eai94.lqA31eSPZ0f6Z1eS4rbreHCKHwsLX8.rZCZ9iMn4KYPyKXPyWxfJfYVS.CY1l.uaQ9vlx4KzMho1L.jFi2bTuIL0jjHxsyfrx4N.MvJ4iZ+ZWVBj+CtPnTNNQ7WXFuYseO4h2d44G8lN+41mZpnIdBQhOOB2q.xlqW2s5iBBoR3JwEhjw1wa6Pl5PBbHRvxXYgjSf8PSnDwvgPyFrY5TZhOQJHJn+LIRnBv9tbIz.FtyG.yHdZdJ5ei2FbqvRrETNRx+.heCCsDeNzQBNCvFYbMD3RaHjWR9PAdzbcl35ZHRP0YzGiQc6ojMgFC6TETEnxF82bnt4RLeFzjKiRLNYGjQYMjR2knjXeCQIHShqtHX.x+kn+A3Fxu6eXtsLFbdfk7AludqF+D5ztPRfc0rXFr6t5RArmRDz.53IvtwjeqlL81QP3RErbK8hbXmEsrGoiHXk8Tv9A2tr9Hl5Og6aXioZHlfBXdsdSibTxrjywPxIFmqBN.WrcMXiBnqHreAIympi7cSXwzjz8LfUmtynzHM5rLMUX+hTMQm+Xb2f40HxKuFaI0eQKePvXKYPtn2yFogic2OD942Y5pU2zjFfr0VPDY8Kutd7DYfsoIhlja48y6kTMs103py8wD6nEQpBUGUMFlljE6da1n2DHQ4kabLiww.iS2gM23XZiCBQFm.P1kWeqljaY8gTQrcjF0fGfxEQkh6Hrevx0kz7xxpYR33GS0fhTAjEq6ConIpKXS6MYfdkbTyawt9vOt80BSSkdKSg8wFjGmg7iFuXuPLMJbNwmlbGKRWeimqXThXBTtaKROnEr1GgIuligaa9QVGO81QgwAzbHCBAtcfZul6fgJfqgvo5uDVJ1YotuAqSOFkuztQd7TWxfmZ7KUSSCf8jPMcPphxqMw0sCY0pyoPt6Rml.jwGSOKktTsFNEBbP0NQXxhjQzY5PscBCUzx0zZZyNS1hhZcM8pO70VeGYkmZ5vUyvMeJFtYIFvZZnL1tvh4uucCxYc6AM8DSfV2PHlAGgvc2+8+3e1pwXo9QVzglEMQuPv98uqSsAvp1ud0hqTLiSSh81aW8v7sZDQWHTr2ltfgNijGhZ3vUhCqGSDggf.WEZip9LLZGMY7.VhCbjnvIrbBgAeVdZpW7kMMkmo8PABEQch3p2FyRe9LQnONkDd+im8xJs+Bb265bJDivwwRgAzEiGNEMmRmxtGNkpY3r0KeJSdmRDqocbrHBkPoelRi8qyFcCC.Vbebrs7.h0LqRkKUAT27razSZ.B8E+sRlwmMSWTDxxSTXU5WUdoIJfIwez.jvnqB+IgT0xyyhS5mh.BKKMDINnXjjqlW7MA7SXH2Fe1gb+RMwuobWtxKX013ZqvFg.1+OrwzWMvWWt8vgPqvEF3yKe16epuGfeD0aNhwH3TAIbLO4hIi6AMN8Xf1ivIewTl0vjVyyMvmQOPOVju9g+K7IEoK9boTjtYHsFS8RD+fmoXDe4C+bMDvlhzubl0KeN9Lw0RWfVzOOl6y+AOukE0iXr4SkwsepL15ox3NOUF28ox3dOUF2+GmQ7UUczDkXrorwx57ts0czJUpcDEx.0YqV+O.znjCC

@d-healey
We should check whether this also applies to plug-ins that have been compiled with a current version of MacOS.

@Christoph-Hart
Great! Thanks for the snippet! :-)

Hey @Christoph-Hart

In which modulator chain do we need to place the matrix modulator for the filter cutoff? (unipolar or bipolar?)

And how do we need to configure the matrix modulator for cutoff modulation?

Do you perhaps have a small snippet for us?

Many thanks,
Oli

1. Once you have assigned a colour to the “bgColour” property in the Properties Editor, it will always be drawn. Even if you specify something else in the “drawFilterBackground” function.

2. obj.itemColour1 and obj.itemColour2 are swapped.

3. obj.itemColour3 does not work at all, or is always gray.

4. obj.textColour does not work at all, or is always white.

Here is a snippet to test:

HiseSnippet 1278.3oc0X80aZbDDeOLWTg1X2TEE0p9xIdhT45vgoN1sppfASBpFahwNo4onk6VN1vxtz81K1zHK0OO8iQesOlu.8iP+FPm8tC3H9ODQRacskr8N+lY2eyryNyfaIENDeegDYj83QCIHiOwr8HtpW0dXJG0nFxXMSWI1qNkoHxcC7P6NZH12m3hLLV4QZkLxjFE90e8C6hYXtCYlHD5oBpCYe5.pZlzVk+QJiUG6RNlNHg1kJ2vQvqJXh.fPqXV.MD6zG6QN.qUKkI5wX+dHiuxzdqhcencoNv26TbqR3Nc2tv1116rClrSWRQ2Ra4rMtPoBHiasmKUIjsUXEwGYjdWg6n18DmxiNfmR8ocXD8BaTa3jiDWWvb0tnVJpZOJys0jHkOB1kVyhaqDE2tqYSpKcp7YwuOMDvZlEICfFolmdqLG8rSRuBIn2kPIiDTJcDktiYaGIcnZFhlOerYCNbU1EC2SIoRjtnT+QZypBPCtZiA39j5RXwTKxuUgBqaA+39eW1rvckuxhg6Z88VSLwQR.OYegClsuPzuB2sNgvxCpGoccl.qnbuioLhcB67HpphACEbXQ9byoUN8YMmjM7IpKbD.OzJB+ZCIwi5CLtd.2QQE774fT3SiSggLJOoHf6lacqtSTvacKQmWd+ruNaFqG7.uM5B4mUXr7fvM53EkQB69EAoJxfHX6EfWbA3aFhOOphblZ5get18Vn+UCdr9XL2kQtB+65buE3cKv4Vfu81vKgy8HI0ceJm3ei7t6CfC1Bq58+u6sIz0RvOPnHGxyGx3rmm05sg518RwzkAjBFiHuTXcaB40YXddvfND45VuByBHSUDJENe8Uyqt9Zxx+NQUkRnnf2fSUGNjvuplBn3RYvecRiZXEVWTNVFn2PhTQ0TvnF4UPKwnRzYLqQ76qDCC0Mt9Gx31p3dJQEkSV7CQc08jmqdH5rY8Ped4QIWbJ0U0alfQk6Qnd8RzKlVNliQD5dl5BHdXHnLIijSXnYoDfk2Zs0FONz1Y4QZw2cbj3PmOUcCyWm0xJ2zXTC2beqUtnc0N25ZrFbWxYfzu1NbIz0kIN8YBYeenwOA.5hY9jPrJZnHiOh3S+Ev2AbkLHAbsQb7.pS6gDG.XPENlMxmHA8JDpzI9jS3thlXNLSgbtsG1Sh5PdMQ.34UYTm9yAqyDhJ7jTp90ZSrzixAwatQgoB0wRsy1FxMgVnAL1yz2CQNsdnoivbOsFEKEaUH+CuINS0jvCh8srmmHHuoNHOd0UCCxSd9GJ6MQ2kydYpk9kie43nwstvjAvLIB2.FVM+fJZlEC.utla5.8D.bepZTxw89fM8x6JEuiYKpxo2kywTWBGg2f+Svw3Y9ts4dc6B4ZyHXZy5+z+BC3kI57+LyVB1ng8DbpSzSiPRjwL9Q10LqNBUWR94.B2YRz5O+sm+lxOI40KDlSLb9mW9IAXVxn6u96U1kNTvvx22Hu8065oeGSOtm4Tmx5Fddr913lMG+By3KWKcP8lMWW07I+GQviDA51vMwJIE5BadPvf1P8WGBPNNz4TOygQJ8zAQqKnWqIQaB2MbAzzbbLnsdsQLn8DPz.riT7BmnIczuG9nPI.m3get3LlM0qsrQgS+j7M3.3id9BGm42pKXXwk0vMWVCKsrF9MKqgasrF9vk0vsWrg5+y.UBThAQ4sHTyV6EN8jgwdb8LXgovn+Fvbkegn

As the headline suggests, obj.active does not work in the LookAndFeel function “drawFlexAhdsrSegment”.

The parameter always returns 0.
