Happy holidays, guys!

Hey guys! You helped me a lot as I had questions on my HISE journey and there's something I'd like to share with you:

THE PROBLEM
One of the most confusing (read: support-email-generating) things about HISE is the sample folder location. Unlike Kontakt, it doesn't look into subfolders. Plus, since HISE exports the plugins as standard formats, chances are, some people who'd get the instruments might not have had any previous experience with samples or Kontakt and would be surprised that after they've installed the plugin, things don't work right away.

SO...
I wrote a script (ok, two in fact - one is for Mac, the other for Windows) that solves this by auto-generating the link file and placing in the correct folder. When the user runs the installer, there's an option to locate the samples automatically. There's only one requirement for this to work - the samples need to be distributed along with the installer. I'm using Pulse to simplify the download process and it's perfect for that. The most recent versions added update functionality so if a new version of the plugin is out, it will be downloaded into the samples folder and auto-run. I'm sure there are other solutions out there but it's just something that I'm using.

HOW TO: MAC
Create a text file with .sh extension (so for example, yourinstrument_locatesamples.sh) and set it as a post-install script in Whitebox Packages. I'm using it as a separate component named locate samples so that the user has an option to have it selected or not.

Here's the script:

#!/bin/sh

instrumentname="Blisko Cello"
devname="Felt Instruments"

FILE="$HOME/Library/Application Support/${devname}/${instrumentname}/LinkOSX"
if test -n "$FILE"; then
		rm -R "$HOME/Library/Application Support/${devname}/${instrumentname}/LinkOSX"

fi

installer="${instrumentname}".pkg
mystring=$1
echo basename: $(basename "${mystring}")
echo basename + remove "${installer}": $(basename "${mystring}" "${installer}")
sudo echo -n $(dirname "${mystring}") > "$HOME/Library/Application Support/${devname}/${instrumentname}/LinkOSX"


exit 0

You only have to adapt the first two lines - instrumentname and devname. Export the installer as instrumentname.pkg and you should be fine.

HOW TO: WINDOWS
I'm using innosetup on Windows. Here's the whole script:

[Setup]

#define AppName "Blisko Cello"
#define AppVersion "1.1.2"
#define DevDir "Felt Instruments"
PrivilegesRequired=admin
AppName={#AppName}
AppVersion={#AppVersion}
SignTool=signtool
SignedUninstaller=yes

DefaultDirName={pf}\{#DevDir}\{#AppName}
DefaultGroupName={#AppName}
Compression=lzma2
SolidCompression=yes
OutputDir=.\installerbuild
ArchitecturesInstallIn64BitMode=x64
OutputBaseFilename={#AppName}
LicenseFile=".\installerAssets\EULA.rtf"
WizardSmallImageFile=".\installerAssets\install_logo.bmp"



; BANNER
WizardImageFile=".\installerAssets\banner_blisko_cello.bmp"
SetupIconFile=".\installerAssets\windows_icon.ico"
DisableWelcomePage=no
DisableDirPage=yes
DisableProgramGroupPage=yes


SetupLogging=yes
ChangesAssociations=no

[Types]
Name: "full"; Description: "Full installation"
Name: "custom"; Description: "Custom installation"; Flags: iscustom

[Dirs]
Name: "{app}\"; Permissions: users-modify powerusers-modify admins-modify system-modify

[Components]
Name: "vst2_32"; Description: "{#AppName} {#AppVersion} 32-bit VST Plugin"; Types: full custom;
Name: "vst2_64"; Description: "{#AppName} {#AppVersion} 64-bit VST Plugin"; Types: full custom; Check: Is64BitInstallMode;
Name: "aax"; Description: "{#AppName} {#AppVersion} AAX Plugin"; Types: full custom; Check: Is64BitInstallMode;
Name: "locatesamples"; Description: "Locate samples (recommended!)"; Types: full custom;





[Files]

; VST
Source: "{#AppName} x86.dll"; DestDir: "{code:GetVST2Dir_32}"; Flags: ignoreversion; Components: vst2_32; Check: not Is64BitInstallMode

Source: "{#AppName} x86.dll"; DestDir: "{code:GetVST2Dir_32}\{#DevDir}"; Flags: ignoreversion; Components: vst2_32; Check: Is64BitInstallMode
Source: "{#AppName} x64.dll"; DestDir: "{code:GetVST2Dir_64}\{#DevDir}"; Flags: ignoreversion; Components: vst2_64; Check: Is64BitInstallMode

;BEGIN_AAX
Source: "{#AppName}.aaxplugin\*"; DestDir: "{commonpf}\Common Files\Avid\Audio\Plug-Ins\{#AppName}.aaxplugin"; Flags:ignoreversion createallsubdirs recursesubdirs overwritereadonly; Components: aax
;END_AAX

; PRESETS
Source: "{#AppName} UserPresets\*"; DestDir: "{userappdata}\{#DevDir}\{#AppName}\User Presets"; Flags: ignoreversion recursesubdirs;


; NOTE: Don't use "Flags: ignoreversion" on any shared system files










[Icons]
Name: "{group}\Uninstall {#AppName}"; Filename: "{app}\Uninstall{#AppName}.exe"

[Code]
var
  OkToCopyLog : Boolean;
  VST2DirPage_32: TInputDirWizardPage;
  VST2DirPage_64: TInputDirWizardPage;
  SamplesDirPage: TInputDirWizardPage;
  SampleLocation: String;
  AppDataFolder: String;


function SampleFolderLocated(): boolean;
begin
  result := FileExists(ExpandConstant('{userappdata}\{#DevDir}\{#AppName}\LinkWindows')) and (not IsComponentSelected('locatesamples'));
end;


procedure InitializeWizard;

begin

  if IsWin64 then begin
    VST2DirPage_64 := CreateInputDirPage(wpSelectDir,
    'Confirm 64-Bit VST2 Plugin Directory', '',
    'Select the folder in which setup should install the 64-bit VST2 Plugin(you can choose not to install this version later),  then click Next.',
    False, '');
    VST2DirPage_64.Add('');
    VST2DirPage_64.Values[0] := ExpandConstant('{reg:HKLM\SOFTWARE\VST,VSTPluginsPath|{pf}\Steinberg\VSTPlugins}\');

    VST2DirPage_32 := CreateInputDirPage(wpSelectDir,
      'Confirm 32-Bit VST2 Plugin Directory', '',
      'Select the folder in which setup should install the 32-bit VST2 Plugin(you can choose not to install this version later), then click Next.',
      False, '');
    VST2DirPage_32.Add('');
    VST2DirPage_32.Values[0] := ExpandConstant('{reg:HKLM\SOFTWARE\WOW6432NODE\VST,VSTPluginsPath|{pf32}\Steinberg\VSTPlugins}\');

  end else begin
    VST2DirPage_32 := CreateInputDirPage(wpSelectDir,
      'Confirm 32-Bit VST2 Plugin Directory', '',
      'Select the folder in which setup should install the 32-bit VST2 Plugin,  then click Next.',
      False, '');
    VST2DirPage_32.Add('');
    VST2DirPage_32.Values[0] := ExpandConstant('{reg:HKLM\SOFTWARE\VST,VSTPluginsPath|{pf}\Steinberg\VSTPlugins}\');
  end;
end;

function GetVST2Dir_32(Param: String): String;
begin
  Result := VST2DirPage_32.Values[0]
end;

function GetVST2Dir_64(Param: String): String;
begin
  Result := VST2DirPage_64.Values[0]
end;

function GetSamplesDir(Param: String): String;
begin
  Result := SamplesDirPage.Values[0]
end;

procedure CurStepChanged(CurStep: TSetupStep);



begin
  if CurStep = ssDone then
    OkToCopyLog := True;

    if not SampleFolderLocated() then begin
    SampleLocation := ExpandConstant('{src}');
    AppDataFolder := ExpandConstant('{userappdata}\{#DevDir}\{#AppName}\LinkWindows');
    SaveStringToFile(AppDataFolder, SampleLocation, False);
    end else
end;

procedure DeinitializeSetup();

begin
  if OkToCopyLog then
    FileCopy (ExpandConstant ('{log}'), ExpandConstant ('{app}\InstallationLogFile.log'), FALSE);
  RestartReplace (ExpandConstant ('{log}'), '');
end;

[UninstallDelete]
Type: files; Name: "{app}\InstallationLogFile.log"

What you need to edit is the first block and the banner .bmp file if you're using that.

That's all folks. Hopefully it will be useful to some of you!

Ok, to hide the popup, you need to comment out line 130 in FrontentBar.cpp file (PresetHandler::showMessageWindow("Sample Folder changed).

The "The sample directory does not exist" text can be changed by editing line 197 in ModulatorSamplerData.cpp (the one below "sampler->getMainController()->sendOverlayMessage(DeactiveOverlay::State::CustomErrorMessage,").

Hope this helps somebody! :-)

Feature request: global modulators on FX plugins!

Done: https://github.com/christophhart/HISE/commit/7028aa13c3c5612bf152620a3d1a8ca94702bc8b

Bug report: interruptions in audio when using convolution fx plugins and Cubase’s Direct Offline Processing: https://forum.hise.audio/topic/4247/cubase-direct-offline-processing-audio-dropouts-on-fx-plugins/9

@ustk I’d add to that that the experience of playing an MPE keyboard is way different than your standard keys + mod wheel, so I’d recommend getting at least the Seaboard Block to get it right for the users

@Casey-Kolb I think it's because AAX doesn't support M1 yet

I figured it out and thought I'd post the solution here, maybe you'll find it useful. Create a file called YourInstrument.sh (I used SublimeText to do that but I guess you can create it in whatever really). Load it into Packages as a pre-install script. The file should contain the following code:

#!/bin/sh

FILE=$HOME/Library/Audio/Plug-Ins/Components/YourFile.component
if test -n "$FILE"; then
		rm -R $HOME/Library/Audio/Plug-Ins/Components/YourFile.component

fi

exit 0

If you have separate packages for AU and VST files, each can have its own .sh script with a path to the file.

What the script does is it removes the specified file before the install progresses. Done!

Bug: convolution reverb volume changes when sample rate is changed.

Bug: distortion in the high end when using IPP and convolution reverb. It’s there even when setting the minimum sample rate to 9600. Makes IPP unusable for serious work. When HISE is built without IPP, there’s no such issue.

@d-healey I knew I was missing something! Thanks again!

I have a couple of global modulators in a global mod container. Is there a way to choose which of the global modulator is used via scripting, instead of the dropdown?

HiseSnippet 1224.3oc6X0sSiaDE1NIdEv1tZoEUUU0J4K5ErsqVk.YCf5Eaf.gFUBDgyxVodwpA6iSFg8LtiGSKppOC8UpOB8QYeCZOisSrMjExFEPnsjKrxbNyYluyuyYldBtMDFxEZ5K0+h.PS+SLrtfIG1ZHgxz5rql9SL5RBkfvLgzNWDPBCAGMc8x6qHnuXEs3eu6U6P7HLaHijl1IbpMb.0mJyn1q4OQ87ZSbf9T+bytdyN1bVKtGOBwSYipZAD6yHCfCIpoUxP6GIgC0z+NipurA.artqiCY80cZznwVatU8spQbqVmbZsFaUes5ar1la3po+n8bnRtvRRjPnldkc3NWXMj+arjM3DZH8TOPMnllEtyIjay8bTpn5+ZsFR8b5MxPEpgKZuLyV4Dy1JFcoNzwzyLeOMlgYlD4Mf5kJBuxEfWs2G7l.jzyAoJIPZYCKaAMPlwQgmGazggdSWB5mxCkj4po+2Fs33DXxW3SNCZKvAiEX0FUq9bS7yy9A2HlsjxYlb1gbIbDa0mszerzhK8mKYdYVttSjmZaDbOOPLQ1pPCw0I3prH+SAwyMOm3EAimHp9EsoOZ5ro1IZctIxYcXT4QAP53rfhZSvCnkZ1v+85N6RjDkSIkFNu.PHoJ3nuKbNlRj3hVzXWH7LIO.SJth+Cib3NQdDYwvIURWJCzdTvGpbTrPp7h7IkWNFqx62dTcho.STamR3trQOpzd3jwaoIfWzpcai2zL1O0XOWWvVlA1JFs+4qM8btCkERfxWYruG+ThWlADiaPTAIoreSJayw7MGOgZWSA4+YZKHGL0Ej0KOuJXU41pF5cZ78meEWS3bMi7C3PoR4f7xIP1v3f1GkZAw+kAxZ2LH2gFv8HBE+1B3Wi.lcN9KzTEszIKXq4e07MjyAWtvOsz13U5.X.tm4ozG7C3XaF14CLs74b4PJaPwXvUZd.mGrGifVDm7KRugjP0gKgfrvxfKaedRKKs731mkmYmALt.RNvJO8VQgRt+HEHtUCKIDDWFW+WLZT+E3O2uW8cqV3m0OZ9LVa90.PooNhUEIL1kqhItmeFRBhGGDdOAw2TJ1Z2coXOs4CoXOjh8wWJ1L2XY4+e1X4w7HIlb2kHEzeGKMcXjuE14lMfHgw.ObiLzKoxESFWUMNNgFXNwC9W7WJyZpw5oLqMhYd08IIp6iMrvFQiezfXk8KhGapxzM2GvVTuZCG25sodjsD299BBKLfGVXgs.eZeNSY0yH95PPE7erJRpPQKNQLQVu6UsQkbhxXQjQh3Pxs84QrBUNub6ySYmeEuxWt4+Qae02pWycFapdwQ30h5G3A6wNG7v60Gi2OCuHuKIxSNhZw.9tbFOXHmQKbb7w.lnNX.HxqGST41VJI4OlcklGCd.Iej8217.LhjHPaFbc1k45SLMQe2WZj.WSUVp48pmpH891ec5s1T.7DhfRXxw5QrJXN5ZcwpP5T9ft9DVQoOIFqpIbNHjISNlXRSOXGP303YP76ZEObt4qd3Tz62mhdWrG9DaA+s1IOVpJ+cgXJndyheN8EM5pFaVSK9ATy6i8wSEdqscwk5JBt1rJ35ypf0mUAe4rJXiYUvMlUA27lETcn81Q3soRRY0z51aujRJ5iuDmdYs+C.9MAMM

@Christoph-Hart thank you! My UX brain actually though it's a message I should read, that maybe would appear on hover yet it didn't ;-)

What does the exclamation mark by a scriptnode envelope mean?

@aaronventure +1000000000000

@Oli-Ullmann great, thank you!

Hi guys! I'm lookng for a way to trigger some extra notes on a single key press. Say I have a sine generator, and play a note C3. I would also like to add C#3 and D3. I guess I should use the onNoteOn thing with hte MIDI processor? How can I achieve this?

Thank you!

I'm trying to get the Scriptnode Synthesizer respond to a MIDI transpose module inserted earlier in the chain, but I can't get it to work. Here's a very minimal snippet - just a file player, and a built-in MIDI transpose script on the cotainer:

HiseSnippet 1532.3oc6XssaaaCFlJ1LmZZ2ZQJv1c9hcQ6PQfkywhcQcNXuZr5Ti3zfdW.qDcLQjH0jnShaw.1E68XuJ6UYuA8MX6mhRQTNJI1F8DVmCPf3OI0+G+9OR0IT3PihDgHqEObX.EYsDt6Ptr+t8ILNp0dHq6gaShjzvJZQ6LLfDEQcQVVk9Yk.qEJih+89msCwivcnYhPniDLG5KX9LYlzN0+ElmWShK8PluwpWqdKGAeWgmX.fmR3pn.hyojSn6STKaFL54jn9HqeDuZMxpq9zMqVy1t2l0Vumsc0MV0tGYMaXlZDZsmViXSUHY1FtLoHrqjHoQHqx6HbG1su3btVAGwhXuwipFXi5BZVKtovyUcDUOi1sOyysSJQEgPV3NYzVIMssLtMykco7L56aimnR1NLIPqYxCuR4fm80AuBfjkAjJqgz8wccBYAxrYT34N3VbvZ1i.riITzqEY8W3cEvB3xU7ImRaFBCtbCOZipUeRE3eO9m5Mf6HYBdEAeegj9R9id7huawEV72VrxnS0qWgyoTSnvyiFV3zJWivaZiOhOv+MzvmT4Lh2.5kKDN944zYGON0QepMVnf2hyjuLflLNyovt.K.Jg1fmdUq8HRhxnjHCVW.MTxTvwZO5YPHg1Ds.dOZzoRQ.DTbE6G34HbG3Qj4cmTAcIS.7QNanxPwiXxglAki5iU954ipEFBT3ocLg68wcXRm9Ei2YJ.u.q8wFuIQr2E2nWOpiLCrkwMe8MFd9AGJyeM4bWJNHDFQCs+PjwMXry3ZU5lxHUcBxH8QKIY4wKf9VxgWPBykvGFR3QAhHpNW4cMDj2Nbo7s8EC3FL8V0+fkS++SI70XJgERghtfbbhgXn78IR3BWZkXwzHVzm7DDo8I7D7jTSdj1vviWLQd+Zi0eyzo0rewj5w9yZbcowy47VxNtPJF6x7C7nM3mQ8f9Yhw3CfFX5QF3ISkl2arsfKB5K3LGSGvCnxP1ImPCMwdgGnskR3F.YRVt9ATOJIxvC8Gp+BnLIID3I5TxESdq0EZu9NrFtUTgPU9uQ93Re0mO9lnt4wMtPFRr+B2Bm.yZetf4AhARF+j1DHr+BH4+9C76B0Sbn.D4bpmpff0LpqPoGWUMVAntTta7f+A9kLosZrUxj1oSZb6q8oxyEgmFG4l7LxZNcW06EEjJ5HZXjxY2ZNb0Uf+Pa64INuivaXZBK0oIV3tB+.VRrAvb5gofOsAP8I34jnCILOUmLcGDAWcz8k7tvhiKAq7V2ONM0bMIN.MOrCAJtCQfNoc6uhiwc.LPalkKl4AKRGRHwmBWLORiT82HI2lT5JszslPAn6qXI02RwpjZdMMECpY0ed.enbnFE4.4CM.Y1RxiKMFLeEiKDlw.ByEu+Z4U+8hUOzhQrxy4Iq0Z5ttMMZbWbcpc0HHHXFkpmEGWF4HU2KJxT88K1OtkFDJKA4gjvSnxnjK3yoNZOi3yPKWEV6Al7iC7HCUsmcokRM2cvMCo+5Ap2CBYXCQHCFXjWPNh3A.QDRWwXAEPFi7BlDNQMETk+hzOgw1CbYhlvaKJ2HEgwcoWjF.1.HIWHIP71RCJMOeVkubDXrZy3IjbVUk1jKFUV8tRZPW1ayUYu6ozy0TRt9Gh4sNvI9MPMXSyXlFR5U4JxQSNz.XLQPaVnYN4Ufz6eVwP58O6VfzZ0uBjp+mEvVPZxqEReC9.gPpbGG.4mFNB1982UuPrAxMw17Sokr9e+1+3FnKyvjwly1dfT3Crb7EIyGbciQ8KgaEcjZVGhWp1F4Ejy6EqKptKntd8PYD.VUIw3viw1v3bSlG5ZYlYQhx6LFqokwYodNdGVfviDNtZcYXx0qV0dqpat0F1qVaK6ZqOBHJbI2FldnIldEex.0zSEKhOBtkgipqkwVW1EnK6hz0T3hriPbpOItYio6q99on0nOE5vm3DJNNoDsh.mOVBTagGWPZAba03J1nyFMYgpr8wNN4eUWYi0l1Mt5ztw0l1Mt9ztwMl1Mt4ztwst8Mp95HIIVUc4.I26zPWj2pAm.WFHtsCz+BfFpN5H

I tried both with single samples, and sample maps and unfortunately, the synth module is ignoring the transpose value.

The file_player doesn't seem to respond to incoming midi notes' pitch.

Is it a bug @Christoph-Hart or am I missing something extremely obvious?

Thank you!

@ustk genious, thank you!

@ustk sorry for being a little bit immune to wisdom, but I got stuck at this part:

and modify the loop in reconstructFromAccumulator() to account for this 2D array

Thank you for your patience!
