@Dan-Korneff I tried to assign the code that you shared above to snex, but I get tons of errors.
Sorry for the inconvenience, do you have a chance to share the snex code directly?
template <int NV> struct LUTSNEX
{
SNEX_NODE(LUTSNEX);
// Constants for the Lookup Table --------------------------------------------------------------
int tableSize = 200; // The size of the lookup table array
float xMin = -1.0f; // Minimum input value (start of the input range)
float xMax = 1.0f; // Maximum input value (end of the input range)
float xRange = xMax - xMin; // Total range of input values
// Lookup Table Data ---------------------------------------------------------------------------
float lookupTable[tableSize] = {
-0.356490f, -0.357427f, -0.358393f, -0.359388f, -0.360412f, -0.361464f, -0.362544f, -0.363653f, -0.364790f, -0.365954f,
-0.367146f, -0.368366f, -0.369613f, -0.370887f, -0.372188f, -0.373515f, -0.374870f, -0.376251f, -0.377658f, -0.379091f,
-0.380551f, -0.382031f, -0.383487f, -0.384854f, -0.386069f, -0.387067f, -0.387784f, -0.388167f, -0.388236f, -0.388037f,
-0.387613f, -0.387010f, -0.386272f, -0.385446f, -0.384574f, -0.383703f, -0.382877f, -0.382142f, -0.381541f, -0.381120f,
-0.380925f, -0.380999f, -0.381387f, -0.382135f, -0.383288f, -0.384889f, -0.386944f, -0.389391f, -0.392161f, -0.395186f,
-0.398397f, -0.401724f, -0.405101f, -0.408457f, -0.411725f, -0.414835f, -0.417719f, -0.420308f, -0.422534f, -0.424328f,
-0.425621f, -0.426345f, -0.426464f, -0.425989f, -0.424939f, -0.423329f, -0.421179f, -0.418503f, -0.415321f, -0.411648f,
-0.407502f, -0.402900f, -0.397859f, -0.392396f, -0.386529f, -0.380274f, -0.373649f, -0.366634f, -0.359082f, -0.350815f,
-0.341658f, -0.331433f, -0.319963f, -0.307071f, -0.292583f, -0.276464f, -0.258907f, -0.240127f, -0.220341f, -0.199765f,
-0.178613f, -0.157102f, -0.135447f, -0.113863f, -0.092567f, -0.071774f, -0.051659f, -0.032214f, -0.013375f, 0.004921f,
0.022736f, 0.040134f, 0.057177f, 0.073928f, 0.090451f, 0.106808f, 0.123062f, 0.139276f, 0.155513f, 0.171836f,
0.188308f, 0.204992f, 0.221950f, 0.239246f, 0.256943f, 0.275078f, 0.293520f, 0.312062f, 0.330498f, 0.348620f,
0.366224f, 0.383101f, 0.399047f, 0.413853f, 0.427315f, 0.439226f, 0.449378f, 0.457566f, 0.463622f, 0.467645f,
0.469852f, 0.470458f, 0.469678f, 0.467729f, 0.464826f, 0.461186f, 0.457023f, 0.452555f, 0.447995f, 0.443562f,
0.439469f, 0.435933f, 0.433164f, 0.431234f, 0.430080f, 0.429634f, 0.429825f, 0.430586f, 0.431847f, 0.433540f,
0.435594f, 0.437942f, 0.440514f, 0.443241f, 0.446055f, 0.448886f, 0.451665f, 0.454324f, 0.456793f, 0.459003f,
0.460886f, 0.462372f, 0.463417f, 0.464063f, 0.464372f, 0.464405f, 0.464224f, 0.463891f, 0.463468f, 0.463016f,
0.462596f, 0.462272f, 0.462104f, 0.462155f, 0.462484f, 0.463117f, 0.464024f, 0.465173f, 0.466533f, 0.468071f,
0.469755f, 0.471553f, 0.473432f, 0.475361f, 0.477308f, 0.479239f, 0.481124f, 0.482929f, 0.484623f, 0.486174f,
0.487549f, 0.488716f, 0.489644f, 0.490299f, 0.490650f, 0.490665f, 0.490311f, 0.489556f, 0.488369f, 0.486716f
};
// Define the amount and types of external data slots you want to use
int NumTables = 0;
int NumSliderPacks = 0;
int NumAudioFiles = 0;
int NumFilters = 0;
int NumDisplayBuffers = 0;
// Initialise the processing specs here
void prepare(PrepareSpecs ps)
{
}
// Reset the processing pipeline here
void reset()
{
}
// Process the signal here
template <typename ProcessDataType> void process(ProcessDataType& data)
{
for (int i = 0; i < data.size(); ++i)
{
float input = data[i];
// If the input sample is below a small threshold, treat it as silence to save a little processing
if (Math.abs(input) < 1e-6) // threshold value for silence
{
data[i] = 0.0f;
continue;
}
// Normalize the input sample from its range [min, max] to [0, 1] so you can index the table
float normalizedX = (input - (-1.0f)) / (1.0f - (-1.0f));
// Scale the normalized input to the lookup table index range
float scaledIndex = normalizedX * (tableSize - 1);
// Get the integer part of the index
int index = static_cast<int>(scaledIndex);
// Get fractional part for interpolation
float frac = scaledIndex - index;
// Interpolate between two points in the table
float y0 = lookupTable[index];
float y1 = lookupTable[index + 1];
float output = y0 + frac * (y1 - y0); // Linear interpolation
//If the output is very small set it to zero to prevent denormal numbers
if (Math.abs(output) < 1e-10) output = 0.0f;
data[i] = output; // Process with lookup table
}
}
// Process the signal as frame here
template <int C> void processFrame(span<float, C>& data)
{
}
// Process the MIDI events here
void handleHiseEvent(HiseEvent& e)
{
}
// Use this function to setup the external data
void setExternalData(const ExternalData& d, int index)
{
}
// Set the parameters here
template <int P> void setParameter(double v)
{
}
};
