Hello!

I thought that maybe for some this Inno Setup script could be useful. It installs the plugin + samples automatically on the user's computer.

It does the following:

1. Asks the user where they have their VST3 plugins folder. {commoncf}\VST3 is selected by default, but the user can change it.
2. It then asks where you want to install the samples.
3. And finally it creates the LinkWindows file with the chosen location of the samples.

(In this case I also added the file "AudioResources.dat" so that it is automatically installed in the userappdata folder)

In this way, the user simply opens the plugin and already has everything configured.

Paying attention to the * symbol at the end of the source file location because it includes the folders inside the selected folder. For example, inside the "D:\Downtown Grand Piano\Samples Folder*" location I have the folder called Downtown Grand Piano Samples. Inno Setup will include the folder inside “Samples Folder”, which is "Downtown Grand Piano Samples" (You can check the Inno Setup documentation if you need to understand this better.)
Then the linkWindows file is autogenerated with the location chosen by the user + \Downtown Grand Piano Samples at the end.

(I received help from GPT to automatically generate the linkWindows file, although it took me some time to make it work properly)

[Files]
Source: "D:\Downtown Grand Piano\AudioResources.dat"; DestDir: "{userappdata}\ZAK Sound\Downtown Grand Piano";
Source: "D:\Downtown Grand Piano\VST3 File\*"; DestDir: "{code:GetVst3Directory}"; Flags: recursesubdirs
Source: "D:\Downtown Grand Piano\Samples Folder\*"; DestDir: "{code:GetSampleDirectory}"; Flags: recursesubdirs createallsubdirs

[Code]
var
  Vst3DirectoryPage: TInputDirWizardPage;
  SampleDirectoryPage: TInputDirWizardPage;

procedure InitializeWizard;
begin
    SampleDirectoryPage := CreateInputDirPage(wpSelectDir, 'Select Samples Directory', 'Where would you like to install the samples?', 'Select the location where you want to install the samples (2.58GB). You can use an external drive if you have one.', False, '');
    SampleDirectoryPage.Add('');
    SampleDirectoryPage.Values[0] := ExpandConstant('{commoncf}\VST3\Downtown Grand Piano');

    Vst3DirectoryPage := CreateInputDirPage(wpSelectDir, 'Select VST3 Directory', 'Where would you like to install the VST3 file?', 'Select the default location of your VST3 plugins. In most cases, there is no need to make any changes.', False, 'Size: 29MB');
    Vst3DirectoryPage.Add('');
    Vst3DirectoryPage.Values[0] := ExpandConstant('{commoncf}\VST3');

 end;

function GetVst3Directory(Param: String): String;
begin
  Result := Vst3DirectoryPage.Values[0];
end;

function GetSampleDirectory(Param: String): String;
begin
  Result := SampleDirectoryPage.Values[0];
end;


procedure CurStepChanged(CurStep: TSetupStep);
var
  LinkWindowsFilePath: string;
  LinkWindowsFileContent: string;
  SampleDirectory: string;
  BaseDirectory: string;
begin
  if CurStep = ssInstall then
  begin
    BaseDirectory := ExpandConstant('{userappdata}\ZAK Sound\Downtown Grand Piano');
    ForceDirectories(BaseDirectory);

    LinkWindowsFilePath := BaseDirectory + '\LinkWindows';
    if FileExists(LinkWindowsFilePath) then
      DeleteFile(LinkWindowsFilePath);

    SampleDirectory := GetSampleDirectory('');

    LinkWindowsFileContent := SampleDirectory + '\Downtown Grand Piano Samples';

    SaveStringToFile(LinkWindowsFilePath, LinkWindowsFileContent, False);

@bendurso Well, I just made my own svg paths for the waveforms. If someone needs them, here it goes:

Sine
110,109,0,0,0,0,0,0,72,66,98,0,0,200,65,0,0,0,0,0,0,150,66,0,0,200,66,0,0,200,66,0,0,72,66,101,0,0

Saw
110,109,0,0,200,66,0,0,72,66,108,0,0,200,66,0,0,0,0,108,0,0,72,67,0,0,200,66,108,0,0,72,67,0,0,72,66,99,101,0,0

Square
110,109,0,0,0,0,0,0,200,66,108,0,0,0,0,0,0,72,66,108,0,0,72,66,0,0,72,66,108,0,0,72,66,0,0,200,66,99,109,0,0,72,66,0,0,0,0,108,0,0,72,66,0,0,72,66,108,0,0,200,66,0,0,72,66,108,0,0,200,66,0,0,0,0,99,101,0,0

Triangle
110,109,0,0,0,0,0,0,72,66,108,0,0,72,66,0,0,0,0,108,0,0,200,66,0,0,72,66,108,0,0,22,67,0,0,200,66,108,0,0,72,67,0,0,72,66,101,0,0

Random
110,109,0,0,0,0,0,0,72,66,108,0,0,160,65,0,0,72,66,108,0,0,160,65,0,0,240,65,108,0,0,32,66,0,0,240,65,108,0,0,32,66,0,0,160,66,108,0,0,112,66,0,0,160,66,108,0,0,112,66,0,0,160,65,108,0,0,160,66,0,0,160,65,108,0,0,160,66,0,0,112,66,108,0,0,200,66,0,0,
112,66,108,0,0,200,66,0,0,32,65,108,0,0,240,66,0,0,32,65,108,0,0,240,66,0,0,180,66,108,0,0,12,67,0,0,180,66,108,0,0,12,67,0,0,32,66,108,0,0,32,67,0,0,32,66,108,0,0,32,67,0,0,140,66,108,0,0,52,67,0,0,140,66,108,0,0,52,67,0,0,72,66,108,0,0,72,67,0,0,72,
66,101,0,0

They're SVG paths. So you can customize them within a panel :)

@oskarsh Another friendly bump.

I want to use it to move panels down/up.

@d-healey Thanks for your comments about my brand. You helped a lot for it, infinitely thank you :)

@d-healey oh, I found the solution on this post: https://forum.hise.audio/topic/4355/changing-impulses-in-scriptnode/15

@d-healey It works on mine, and it's a M2. I didn't receive any complaints either.

@d-healey said in Compiling macOS Components and VST3 Doesn't Put Them in the Project Folder:

In a recent commit of HISE Christoph removed the copy step so it should no longer be moving the plugin files automatically (although this might only apply on the latest MacOS version I'm not sure).

I can confirm. I'm using Sonoma 14.3.1, and the compiled plugins are now located inside the project folder. That was a good surprise :)

@ThinkTank You have to add this:

const var ParametriqEQ1 = Synth.getEffect("Parametriq EQ1");
Engine.addModuleStateToUserPreset("Parametriq EQ1");

(Replace ParametriqEQ1 with your real EQ name)

@alfaholic This is how to copy/paste components: https://forum.hise.audio/topic/4408/copy-paste-component-following-feature-requests-thread?_=1696542841615

@bendurso I just realized that setting the Source Length to the same sample length (2048, I was using Automatic mode before) and enabling FLAC compression does the trick to obtain the same file as the example.

@David-Healey Haha that make sense too :)

@David-Healey @Dan-Korneff Great news! I was able to fix the issue with Amazon S3 pre-signed URLs and the HISE Server.downloadFile function.

Thanks to Dan's explanation of the source code (on the other post), the problem was identified:

HISE original logic sees the ? in the S3 URL and assumes it needs to separate and re-parse the query string into a separate parameter object. This process destroys the specific encoding required for the X-Amz-Signature, invalidating the S3 link.

So, I modified the ScriptingApi::Server::downloadFile function in the HISE source code to skip the parameter parsing if the URL contains the S3-specific parameter "X-Amz-Algorithm=".

I think this should be changed in the HISE source code because AWS S3 are pretty common.

@David-Healey I found a post where Dan was using the same amazon s3 links as me.
https://forum.hise.audio/topic/4635/question-about-queued-downloads-from-amazon-s3/26

I'm actually trying to use moonbase, but I got the same links for download.

@Dan-Korneff How did you solve this?

@David-Healey Thanks. It worked with cURL as a background process. I read that if the user has a Windows version prior to 2019 wont work. Should I use powershell for Windows for better compatibility right?

@d-healey yeap :)

@d-healey Thanks, yes it works with curl in terminal.

In HISE, I'm clearing the HttpHeader before starting the download, as I read in the forum, and I'm making sure not to repeat the base URL (just using https://).

It works with links from other servers, but it doesn’t seem to work with signed S3 URLs.

@bendurso The link contains 1359 characters. Maybe that could be the issue? Is there max limit for the link length?

@d-healey The link is the final one. But your comment led me to think the link was different, so I checked it and realized that the download link in Chrome transforms the " into %22 and the spaces into %20.

I can replace the spaces. But how do I transform the " into %22?
Because this doesnt work

String.replace(""", "%22");

update: ohh, like this:

String.replace("\"", "%22");

Now the link is identical.. but still doesnt work :(

I'm trying to download a signed Amazon S3 URL using Server.downloadFile(), but the request always fails. The same URL downloads correctly in the browser, so it seems an issue on HISE. The link is extremely long because it contains X-Amz-Security-Token, X-Amz-Date, X-Amz-SignedHeaders, X-Amz-Signature, etc.

@d-healey Thanks for your comments about my brand. You helped a lot for it, infinitely thank you :)
