@HISEnberg Absolutely

Im FFTeing a static file by the moment. Be sure to replace the path

HiseSnippet 1717.3ocsW0uaaTDD+bROT8AHnR7.rJ+CWJVN1tlRRpPjlObaDMst0kBRkp102smukb2tG6tWbbqhDuP7TvKD7D.yr6c9CHEphnVJwdmclY+s+lOt4FpjQLsVp7ZD7zYELuFej+nYBS5AoTtv63C8Z7I9IRUY9KYmSyKxXd6Oqfp0rXuFMV+dnRMZdMO6me+a1mlQEQrEh77dljGwd.OmaVHc3deKOKa.Ml8Td9RZ2euiijhCjYxR.Pq62wqfFcJcB6gTTs078tOUm503l982YmwcGy51Y63a0uWunw35js6rcRbmDZun982glr8sG603CNJlajpQFpgo8Zbs8kwyFkJmJbGvy3Z9X3VAK55MBNYm3AxrX7JhR8NHkmEOrlozdfWFtf2V2wael+I7X9b4K3uO0tAYgEKSfMVaU3s9Jvq6xvqyRv6RfTikfz0bP5F9ihT7ByhcP77g9GKLLUBMZ0XoSWu09iq6efDzPXZmSOkMPAKlaQ3s6zoEA92l2IHnYvVaQFRMoDHCgXRYjDdFK3Lphn4SDzrAvRB4qIGIlvEr1YRZ7cKi4RTN3R49kIIL0cUJ5rvMNX2ezto9GOHUw0FYQ5KGwQKmzdJ8rMvSDNOfXEBVFofGcJ44cdAIikXHOu6KHJ9jTS.j.oMjEX.N9EfAzuxKJFP3DJYvfmRji+IVjoM43DxLYoyOjnL7.jBB2P3B6sCMTaYIxTpIJkXnPrgPEwjy3roVcJjEkEna97rLhlgGgt.7tRNQQyQOTyUwTCk3ne3.VB2Iv8YNmEYAJfxvp6uSfdU+R34PUBITw94RtBbHdHn11ChMtbREvFWZH4162XFoDO5Lva.fjjXEcJZBbkQbAbbaxM2J.PSaMybj.uqirGYYduCCguXUPZDyXOnobQrDnAH4a9srvk6AAwZO88VsvLzPTx9YPIdNUbepBh5nGq3fmvzkYFMPEO+E2g.Gyc+4xe6WAFJWh29IkTULn4aHxjDvssHSfJNxEVD0KlTCU3p.DDCtj5ZDr3VLb9dguIfP1.34Q7Wy1XWR2a0BEb3LAMmG8DpXhUJj8ihezYfIX6P3dAh6aE55aMJJkki51yJD6PNfFAk3Nyc1C2sJqebIMialAatw8g3xFUFkmSAQeocEzaP.2zXGvPd2Jd.FrYhnY0Z2046E7KhrfKpoTKO.rIRBSdKj.pKxe2ieFyUPC4hTRRoHxvkXU.Ex8gd2X5SDMKaoTMFEpHpp4hRKEm1l7JLG+UNCf7aCFfXbvuJvonMisM.HfGnPVG1G.hlUR00l.rjEKFEUngSKmEi1hUtUGGVA5xBV8rPq.1fcN5UW+Ik1XKisOKqtv1BWRHfKFVtWeAgNcc6zqeKRuN821dH2pyW0yhaVDEpd9aY3.bdM3.s0p5jsSnSDbSYLaPEIFFDDVSngHA0pB6aF7FnkZSLVkSOGhTcZ24NnD3NGpQrhZuYPSPslNMNAZ9BcoOOD9qEAqdZdAZwVaAsv0xLV6BEWXB23o.PQSNilUB8jLjMHeQMk8EvB.znDPEzGKp9ZWTpSCqqw1ckZscsdDyuZBYYsHIzLssk.dyKTLHgiEtc2c5AzXchU0ihrDWUveJjP3BN0YYzwxyXsqbiU+PWfdy6zL.+r0MCd2JW69drb8AxoqVsd6NWR4pkTda0qWdAa.z0shs.zXHJYoAdTvROgXH1ctKD+qePMTOefLuPJXXv1sM9.S2uvzPqqdhySKR+lrokHIjInNNFIz8kt8zTtAimMmzFe1.R1U8LvF2sfXFWim7CjPmf8kkhXcXmMACrsbpNZLM.y.AQyiuRwCkF1iDgtL9KBH+8sRRtz8vqqRBccTW513vjp+MCCEk4iYpVtxf4JBCLs5TX9u8ovVdHwHG6ujhRwwPw9iJXh21nidUgL3We2wGB0y3naUx.8JXJCGgPiCYmACN6Fjqo+gL8ovDQVcqhyvnsF6teb8XdHi6wgg4ttui88Ne9r0+xi2a1hEOauo7XS5bAu5h8RY3XAykPltm2+bhRXVVYbILxvpC3hUMUa.78JSUhSNJzPIyxulv+aS89tBwa3OjCCrc4XbsKAiPT48AFqdWgO1+Hn0WjYA.ul+fe38yKF34J5m.OpPwg7A+GVlOBpuiXUSRi46MVCyLcq6fqQFXDSDaW7mvmpM6hqaTsY25M8xoQJ4KibUY3aibcqD.SB6at0z+DbMoqmsxaYdNGd4nWFEspq9GF16pZ3stpF1+pZ3WdUM71WUC+pqpga+eaH9tq2szHyckMddmL7HaaqFMbuRfMa06u.pGqzkA

@hisefilo here, lazy dude!

{
"FFTSize": 13,
"DynamicRange": 110,
"Oversampling": 4,
"ColourScheme": 2,
"GainFactor": 1000,
"ResamplingQuality": "Low",
"Gamma": 60,
"Standardize": false,
"FrequencyGamma": 100,
"WindowType": 4
}

@Christoph-Hart Confirmed! I'm an idiot! thanks mate. Anywhere to see docs for setSpectrum2DParameters json object?

Hi mates. How do you do to show de spectrum after doing setEnableSpectrum2D?

I can see it on the object browser but I need it on the ui.

Thanks in advance

@Christoph-Hart got it. Thanks.

I was trying to pack X and Y into a single float parameter, using four digits of precision two digits for X and two for Y.... nasty!

@Christoph-Hart Well, just asking... any way to pass 2 parameters for the panel? X, Y ??

@Christoph-Hart Fix works!!! Thanks man!
I was trying an old commit (a month old) and you comited this fix yesterday!!! Awesome thanks!

@Christoph-Hart yay!!! excellent. Will try it later!!

@Christoph-Hart Well, cannot get it working. Any simple example you can share?

Content.makeFrontInterface(800, 700);

const var Panel1 = Content.getComponent("Panel1");
const var SimpleGain1 = Synth.getEffect("Simple Gain1");

const var uh = Engine.createUserPresetHandler();

Panel1.setMouseCallback(function(event)
{
    if (event.clicked) // mouse down: start gesture
    {
        uh.sendParameterGesture(2, 0, true); // 1 = Custom Automation, index 0
    }

    if (event.drag) // during drag: update value
    {
        var dragValue = event.dragX / Panel1.getWidth();
        uh.setAutomationValue(0, dragValue); // set custom automation parameter
        Console.print("Drag Value: " + dragValue);
    }

    if (event.mouseUp) // mouse up: end gesture
    {
        uh.sendParameterGesture(1, 0, false);
    }
});

@bendurso said in Panel isPluginParameter DAW Automation:

I followed the tutorial of david https://www.youtube.com/watch?v=NYc44pKQHxA

Tried that both videos but does't send parameters from the panel.

@Christoph-Hart Wow! lot of new methods. Will try to implement it. Thanks!!!!!

Hi mates, I'm trying (for the 343^3 time) to get a parameter passed via Panel.setMouseCallback to be received by the DAW to automate it. But cannot get it working. (Ableton & reaper tested)

I've tried:

• I manually adding "isPluginParameter": "1" in object JSON
• Linking to a knob, and setting isPluginParameter on that knob (with and without isMetaParameter)
• Praying

Any tip?

HiseSnippet 1173.3oc6W0saaaCElJwbH1acqYn.6VgdkSQglTRbrCF1pS7OYFcNUaN+scSFsDsMQnIEjnRpWQuaOO6MYOD6MXuAaGJYaIm5lE3sUrBLAaCyyOje7vuy4P4FJ8nQQxPjQoSlDPQFeDt2DgZTiQDl.0oIx3yv9z9wCujDqjiIJlTb411aWAc3j.RTD0GYXr9QZiMJV.k776O6PBmH7nYhPnyjLO52vFyTYRcq+bFm2l3SOgMNm06VuimTzPxkw.vVGaiBHdWQFROlnMaML5qIQiPFOA22wyltSeOBoOYeZsZU5uasp6SnN9NUqr29Ur2u+dUptmGx3CZ4yTxvdJhhFgLJbnzeRuQxaDoKvYrHVeNUOvA0CV4Twskbe8VTKE0XDi66NKhEgfYwMK9sdZ76Q3tLe1b4YwwGlnvLyi7APi0VDdqu.7bxCO6bvaIPxHGjvoPZSbOuPVfJSiFOeHtiPQCGPfyo7P433wGD6yjsYbMRvFFvIR5DfV6WMvMjfaBk0XxUz1gvf4SS4Z11O0rps8VeQI37KRYdMIzzkHnbGyuzbliCopFxwARALn7iSU+3EboGab.mpIUZ+R3iZuZMX.0CbIUsYhdsivSwzowJhp5JiinMHbdefyTdPrvSyYKSuFVtsJU7UkJVTCkHImZEDx.LjnxxOjL7BX1.04Ve8LdfREx5GqnkgsWNiM+7oaNM3Nm4qFUdKymX5jD.JU70I+BelgASo3Xoh9BQ4sJAvnzqKYdaUCFrTc5PWnjyogKUsN6I7tbrrHdbeZ3SgnKOlN2Pf.uHsC+1oc4yJ7ROIyYnTzQvTuHfJda4JnoG+v+NsSShhn4pSkA1EPCULMDLZRuFpTjxbKhaRitRICRrcJmAJUoRz9fY7Z8g.hAr2MvoGHnWNuXR8er9jrJKeUcfXHuYF8.VuOAe.malI3F84XlCSpOhxFNRkWBKxkGOjIbIgP8Hf7mtmCVTXZspMwAZDMWpChE0kpH2xWTtr1Bo6cndgzOlSTKVDQyJmp.NhWHyUmHJhXpI4KE+OVkk6KD2D6xTdiVNFWaIXDHB+afwo0ie.NsrQF.Kfaew6fhuaLue57pIIK+GiyW+5NZihPMobxBApyWjb980WRi1NhqgbIWImDd6v75268oycuOKbu4B5sj4eG9Zg62gwc2n99xc+TbRH+8I.mPId+AvOTWg9+.v86jwJlXXWBzZGZVfga8zCtsoGEfp.JXmbym0zssRGaqGqATOpvOYve.OSU5L+ZRfRmYJemrFiIdgxK8RayqSM2HQBruEI8eJh6pGa5fRZ8mubvX35nW54s3T8FNt8p53Nqpi6tpNVYUcbuU0wpqpi09qcT+1BGL+ctzMIytEHzVK+fThwThxrIHWBY9q5mr9cD9zWNyPHwJTkGIsD94S.aGy4ugMZg2xtdWQuI+3j0D1lZYu5Q+xQ+1O8yOCPst6jFzUw6T0RbxdOuViCOZXCKqyZ0lXepia7tbuq5bj9q0AMcuf8sm+CNm1F9+0VVVn42FO208R64kVDA8+goaElf2Wdg.TW2VIW.2vnkf.kNSk9mPzgVF3

@d-healey absolutely. The good thing in my case is that I am the audience because we are among them. We know the insights. We’ve been using vsts for many many years. At least in my case.

My 2 cents. I insist. If you create a plugin that reads your mind and makes drums grooves just by thinking about it, all marketing techniques will work. If you do a sampler with a string pad. None will. Product is the key in my modest opinion. I prefer to use my limited time for creating.

Just out of curiosity: who is using this in a real project and does it work there? Like except for the NAM loader?

@Christoph-Hart I'm using aidax in a real project, and would love to have NAM implemented.

@d-healey not really, it's just an mailchimp replacement. You can segment users but you cannot automate

@ustk Try Sendy.co with Amazon SES -- super cheap and reliable. You'll need to deploy it on your own cloud server. For sending 20,000+ emails per month, it's unbeatable.

@Christoph-Hart meaning NeuralNetwork.process wont work yet, with a simple 1in 1out float32 network?
Just NeuralNetwork.processFFTSpectrum is working?

@Christoph-Hart Well, I was aiming to implement something simpler than that to begin with. I’ll go for this later, I guess. Thanks, mate, for the tutorial!

@Christoph-Hart said in Just dreaming. Any plans for adding Tensorflow lite?:

I just used it for spectrogram analysis so far

Do you have a snippet or tip??
I managed to load a simple network that infers the double of a number LOL. But cannot connect it.

const var onnxRoot = FileSystem.getFolder(FileSystem.UserPresets).getParentDirectory().getChildFile("Scripts/Models");

const var on = Engine.createNeuralNetwork("onnxNetwork");
const var onnxModel = onnxRoot.getChildFile("double_model_v2.onnx").loadAsBase64String();


const var out = on.loadOnnxModel(onnxModel, [4.0]);

Console.print(out);
