I was curious to see what preprocessor definitions were available and since there isn't much by the way of documentation in this regard, I've put together a spreadsheet and posted it to Google Docs.

Where possible I've included a description of the definition, copied directly from the source code. Descriptions in italics are my own interpretation and shouldn't be consider official.

No doubt I've missed a few important ones (and skipped some of the more obscure ones related to SNEX and rlottie), so if you can think of any more let me know and I'll update it. here's what I could find:

Preprocessor Definitions

And as a bonus here are the definitions that can be modified directly in Projucer.

Definitions Exposed in Projucer.

It's possible to export an AUv3 for Mac OS, just not directly from HISE.

The steps are:

1. Export an AUi as you normally would
2. Terminate the terminal window after it's created the ProJucer & Xcode files
3. Open AutogeneratedProject.jucer
4. In settings, scroll down to plugin formats. Deselect AU, select AUv3 and Standalone
5. Set your deployment target in the release exporter to 10.15+
6. Delete the debug exporter (I got errors about missing files otherwise, should be fixable in Xcode though)
7. Save the project and open in Xcode
8. For local testing, set AUv3 App extension & Standalone plugin to Automatically manage signing, then select Sign to Run locally as the signing certificate (This is required for the AUv3 to register as a plugin, for distribution ignore this step and sign as you normally would).
9. Archive the project. If everything worked you should have a standalone app that when opened will register itself as a plugin.

Similar to lalalandsynth, I've experienced several ui & functional issues with the exported plugin (weirdly, the Standalone app seems fine).

I suppose these issues could be fixed, seems a lot of hassle though since a regular AU and standalone work just as well without all the extra hoops. Probably only worth pursuing if you plan to sell a commercial product on the App Store.

I spent the better part of yesterday trying to figure out why certain parameters wouldn't work in a compiled plugin but worked fine in HISE. Turned out they all had one thing in common, a hyphen in the parameter name. Removing the hyphen resolved the issue.

This is on MacOS, other OSes may be more forgiving.. This may be true for other, non alphanumeric characters. I've not tested further.

Okay, so it seems the problem was with VS 2022.

I uninstalled 2022 and built with VS 2017 (per the original instructions) and now the Faust node behaves as expected.

The trickiest part was finding a way to install the community version of VS2017 as it isn't specifically listed on the Microsoft download page. There's a simple solution though:

1. Visit the Visual Studio Older Downloads page
2. Download the trial version of the enterprise edition
3. Run the installer
4. Close the install dialogue box (not the installer itself)

Now the community edition will be shown as an available download.

@yall Seems to work fine here..

This is just an adaptation of the visualisation snippet, simply replacing the peak node with FFT does the trick.

HiseSnippet 2199.3oc2XstaabbEdoj1DqMwAMEAE4mCTBPoLXn4J6lFj.inqzQn5BgnrbJBBDFt6rji0tyrYlYEESfA5O6iWeB5yPdCZOmY1U6RaZWW1TilxeXqYly4Lem6mYGnjQLsVp7Zs94yxYdsde+gyDlI6MgxEdGtuWqOv+Xp1vTD2V6NKmp0rXuVsV8w3FsVeMO6ue9q2klREQr5s77tPxiXGwy3l5cGr8ehml1mFyNmm0f5Gt8gQRwdxTYAfmU864kSithNlcBEIaEeuVuyAwbiTMzPMLsWq01UFOa3D4Tgi9K3Z9nTFtHzaHHH218kowHhwc81aBOMdPkdq87Z4On1JrpyJ7Q9Gyi42tes032XOfTyQS6QqUlGdqNG7BaBudMf2BfTqFPZMGj9P+gQJdto9DDOum+gBv4jPAydSn3n0ak+9c7u+8tGwsTHiYD.DEzTtlZ3RAIrWXPPvgIjYxBhfwhITRRQZJYq8I4oRCQlPLSXDMerfl1gTnYjSycr18VFkhzYUbKErOKF7qBMPDMkbMMsfAxfZHZvTnshKpPoXBS4gAsSjJh1TjjPR4WwHYx3OSwEi0DpRVHPwdkPNh.TcwSHYLPi0a1gbHYprHMlnKFOloMU.aqtjffyQPWq0BlYpTcEYBSwHbM4YE.8T7hHQnykLkal.anSkSIG0+TGfABS.kJfKLR3vbF8JhUbTKlFmJGQSuLhBNU69cCt28CB1SBtDgoaF8JVeEr3VWT6s1pWGxV85s4WEDb+6eqk7KIOArqra.xPSVLWmmRmQFAFDPSQJezun+rW9iYFmq0ZkH8+VzZT.ZB04ilGEDMjUFwBfLTM52Tj3bxiH1hEcGyL66ndWKwCsz1digUhNbiRMt5RS3JPLuBMlzFbHfHHQTMyRdsk25WlBnFDDJPvwLxQyAUBqDJDGVHeR3lMPsZDf537WBxss9jZ518I86evYWdzAm73y+FfkvO+AewCc5.DZAvhpJglRlyTFNS6vFlODQEjw7qafcaLKx7IEYP0DgfkpIYXPHf9vNfhWyIpZTgD3UUYPRYhwP7Illzv0z.tMPwiH+T.grgSsNxx3Fe475SGjfFHANOL34UZGD0OEJPSjWyTJdrSKhYIzhTSyKprzfMvm7mKAeQoGSC0rQwkikqhKPikDR60FYF+Gcjzu+4yY8jRRaa5+S4hXHMz.085PXlnM6FnF0ELKmA0Db50fa4qcsHJiwNA3MkY98P0iXLMUyyxgv5bJnpVSXo4CDViZaAy49GDB1wpDYHVYOYVNTYSXZuw.Wvr8pdJyU1CzM.CbYLOhlB0B+gBlZlU3XYrJuHZATLn2fET3kBfxLAEjVhA0UFOKTA7af5nJcoamq6FLHDMCXaS0dvEMB5O1NoPDgkQZuYvOErtK9jPKLxHIp2vskP4PzlVlwfBvtJc5h77TqE.i5v6DhPmHi0crhnY3XpTdEARHQh1YvgjcUPUbPaf5xv+5RwqcLkH.hgbBrTi0X4SPWIxQOiEYPSQFWoJimsoHkdktAqa00Xpg1szv8HHssqSPC.gz1R.3UNRBl6cwNDZH+sCAtZHsjFrd0Ox2A0amOzm.6D1s22ao96t4RsgpLcH2bISD2gL6xLtv9eza99FxoW2dH8VhK6Z0FQNWvM7a6xAo+4RM2VTu2lMXGBXbZkhkCcaLsgMdNFEgNTTlVWZ6GzqZOlY.R2YxBCWvp8wisN4wcSfDzcRSa26ls1pu8GdEiQFcCP018e5tSmvML2gHS01uFF3NjEaQqPY00CM2OQZXmVFqE77.xKdTRxBOCSkTxzTPIWzwN0+0vXaQQ1HDnVC8sDBSGM+HW9u5QtZNQXjKytAgRwgfq7zbl3UMmnWY4.3udxg6CFObNsx8pKGA6sO6ZXnW2Taq6uOSekQlaosrFBLGqwd5cqloCy283vjaq4OHz6l5Yhuy1ypW7oaOkGalb6Fa+rsmv3imTOa8eIYauWdzQXnUryN0L+jr336kG.154FeDmXAFfyLq438+hMd6aJD+P+AbSzjEiwUV.FAOx+MvX4iBtq+APxRjoFfq42+aeK7B.e28GTFs.2Id4uue83UyABnw9bi1foEsVAToxGEz5u5WmgkiUjTrykC.5aCcsgVFmAfGFIIUFc0PnY8KmVl6v1tHEsiJGhXYxdem2XyU3q2a4JTN9XpQwgzGevF3FBsZDmJaP45d3ZLfYHT12t3e.+JOLDW2p7vvpCaj+eh60DV+T4e605ccNE23zWlbSnGTfVNEy54kgufywt2.Y5r7IRAOB2xQQER2ICp9Zpf62P0mCcuw38gEZn5T7ohg.w1mY2Z0K.uqUvuqOzgpKnHqbBLNFXX6Si.C6LrbOlHgE7fnVlpazsQuyg04Bf.QT8LbmUBfXlsvE7H7pWSCQ6q1ntmKjEWAIjq3j+g5KvSgVJdWfddTM7Po6rbNjhj56mjX7lCy20mBCHMSy5hG8eN7PhfX6appb+BoHu3NnN.C3bS0Ub.D.GCB1xdUDw.ph5dMJVvn4hcgglxn1PjkpaQyxOef6v2yeH3.sO3x599c10jmRg2Y7XF3ZwhmgulOPye6M8Czj+F+AZNMx.W+4JpPCC9LmfGxx3mCs6zM2DdlaeE6GNCSGZt+dRpZgG8yecePIWHOColBkMupJkoQafUecennvk7CEs1+y8gh9UPy945jsdEFGZeS1AhqYoPtfEi+VH329FypcmOV9XoPVUyr1QeFCJ3OdLluVi8EpP6XLvqkp24i19LVJi1Ln8S29HHXipN1VXZorEg+a+c8Vn+5i8cvkfIfje8Nj1p+e8PZuUl53swcjQiTxKibCqgwo2wtCn2B6mdec+iw0jPuqcswq8kYPUtKihlWTuDiasrL9fkkwGtrL9GVVF+7kkw+3xx3W7ulQrIzNEFYlK0zy63AG3Fgo0AB76VayH79mP3zf3B

@ForeverLive To use a global modulator in scriptnode you need to use a Global_mod node. Like this:

HiseSnippet 2091.3oc6Zs7aabbFeVRMzhx1AxI9PPPaAARN3f5pJJ4j1fdPqDojKQzCVSU0.TfXOZ2ghCzt6rc2kxhIo.FH4PA5gbq.A8P6gdq.8TOzhhB66MEvH9bOzSoWBP5eAseyN6iY4KQtllNMnj.D679226u4iaSOtA02m6gzJeXOWJR6J3V8bB5TqCg4fZTGo8B38H9ATuJxt1pmKw2mZhzzJdaQGZkW.E94K2XKhEwwfl1EBcDmYP2kYyBR6so9ayrr1gXROjYqL6ao2vf6Tiaw6B3oHdUjKw3TxIz8IhoU.izJssIKf60JfDP8g4rE2rWqN766Hm+QLe1wVTQipnVvFI6FUqCyxrYLs5ifMpYJkWTR4WGuGyjkzeJGX4vApjtBUdfVgwAopSAjzTfzBRHcMbKCOlaP5HB7bYbCGPfzl.rZUnHmKR6Q3ZbXBNAqXSNktiGzHYA2X8UW8lUfed8eP6tNFALtSEty97.5AN230W58Wp7R+7kpz+PsaOzwDGiG2xh5MzgERWuwsva3z09Xp2MqbFwpKMYh.4mkmVZx3oFRpVYhbmFNrfCboQs2gaYJ3UhmGTBfhXafrnXDBgmBBkDuPjjnkEyj5gXvlbI7a6vOtJJD7QZw26O8s9hGh5ewKGs3Zb6i4awOOb4WFG2L6VDZIglfyeQbstAfnIypev0+Ce9Fnebi5j.hPmJhj.xzk5EvDbSs5zy.iRoFVYbcp+oAb2PZ11k6HX.ZkuPp97T3dndujFOnstMyzzh1j6yDRaUmA1YbW7v.54vQsDdOtYcpaPGjarvnAbPubzY6vMoUD9jn9LepWUvofG3O.zmEyRY0HE7u3Dx3GAUneOcaBLFVq.zhEPsA91Uw6tyAUptj320xCVur.qs.mafcqJXKcwh3QfSz954.GI6JZPONKKvXWKRPVGfBO8QCHjopdcDtVb.YcOU82ovq3pi0q3jBwqgaxBL5LbLVXHXDLNdVfwnXIWEuc61TifT.t.dm2IuANl7ieQ4w+J3aawOlXkxn.2..Rnx.HeyngqjLdkjITcLQ3e7jFg2chivqUbVE9bgmCQzmM5tuz.hC+4nElVAEXdMILwBWcQbJg6tDfU8hA1VLWtEwSL9NdzeVWpigx3KpKzJZjpTo+w5+DxYz1bO6nHRI6ztzSfyTsmCofSSvulgpBXKaNOnCy4jr5ZWWeWN2caGBvELU2jlcH9hTZ7oAY1FXaOjKy0slE23T0AabhC2iJSSRs+Zc8C31wDPXNpsBntgQe09o327Vq.eZ+sE+9V0feV+fYSazrKsyBSrVpPSHQjKzI9JXb.IJST7dNhxKxTZsmJSI80W+aLwlRfov+2T5qalRKLYJoWvUdlmlUyUDO1DBK906DBuCua.XDuGIviItEy9cskW6.NcGGpke7MahZupncngK0wLrw+A9DMXUQasnAqFOnJIVNlDit+hn9Qgj3HuNxHRwrxu+u7Wm8oXFWVjahmlRPTZh0cUcJj8dRJyedVBp4pc1yw6FlohYkiwXKlsqEcamynVbnGAFeQbcZaRWqf3dypAtG2g61g6vxDK7NTv54jSndpXenDzlAAD0XbWW+NTKJDYLsqWSeW3xUDOfOQyIuX5qd3PkWuLVB2JBylJOMxs+Wyc9LGu4209bk0sHd6yC7HU+JtDNBlq87BlyiflIEXFsOM39buSCsbidFocIIe3jvpAf1zxheeQYBYQZ7.+Hrulbqdw9qzJHmQLJ2zl2UTSQIT+gD+CILKwzZ002EvxANsfIGFeUq3QTO+vM9R3UWA9BlL6G5fpzNDCfA2qIAhjC1dFwUGZECE4UDNUkWhkGG6Uxc.3YGVkSQ97fLpYbkHEUhtfVQkJSKchIZAh6Bhy3J3F9GIF0.Nmijk4FHLwoDVxGIZwxoJgycsgTSG.9dzUTFdxQbXUkRvGJ08ygDuSnA9QkX2gZHkPg7OQMVwXWaBpoZYWuDVRAgk90hddbI5qy7csH81pK3EQ5JOSOBVgiI87Xknsg7ULAEY4EihyFKkqJ3hwsfCcOlyQY+2E.xfbde8spt3tVsXuWlnSsNkdeIqLSLv5BZQhoA15M6BWhCLKMSDTQxGICIif4pg5UPRXqHFZJDJEysPw+r1YEJWFmdy5rbwhSOWD3XCvEAW.igKJ2fKfKNdf7kO7oGHKg2CxNh4Z0KEKO3K9fMdi282swzfkYASAi2zzLEFGu767V+w+0mswHUrtBl6a.WEPDMYnF9JCmacrm0lrkT3qklL95xSoIaIbXxmCHct.Q5szG3n+EOo+i929IexedviV+Cs+6aH+CqSMxxtUO3TcUAawKRWeimdWWWIDLUtiviwfbiQhlR4Wae7RkaCm13kJkdV48Ir7cC58YNb1kBu03PH6LQLDdq6KhQalkvjYEwPyJq4cj6Y5ii29E1uQa7lWKngyul.KH8OVejdn6W3ou95OoeKnG8oe5qNYfA8p+6GGBlh3ezTqvt1iFToYM8YgRyyR8068R0eRD+Ooz3YNe8+468Q4wVc137dlQ5i6nKiiK7+Xj48mvTIISK88cX5SCEC2Io5HzFFXqTS3az4+k4NB8katzfG0OMn79kL6S8JYoO527Je2+wq821XxHigb2BkD3FfDRdcOl8txSV5up1uz5y+0OI+DfLqOzVb9o1jv6EmqWho4xs3sIFd76Fc2EAUtXXOfEfS3KpXY7dh1URdutDpxqhrYlr6ZXHJOz2oJBM70rVNVy54XM2JGq4MxwZdybrluWNVy2erqQT77nnjBMQnilaKClqk7uZBo68egtcpAF

One important thing to note is the global_mod nodes index parameter has a step size value of 1.0, meaning it will increment from 0 - 16, ignoring the decimal points between. However, when we patch this up to the parameters in the network and connect our combobox (dropdown menu) this doesn't work as you might expect as the combobox ignores the 0 and begins at 1 by default.

You can fix this with scripting , or if you're lazy like me, you can change the step size of the parameter controlling the index to 0.1, like this:

You can send a tempo synced signal to the samplers pitch with scriptnode. This example probably isn't too accurate as we're converting MS to frequency rather than semitone, but I guess it should be pretty trivial to work round this..

HiseSnippet 1729.3ocyX8zaaaCEmJNLoIKqXsqG1gdPGFJx.5hSR+2.1.hiyeZMZbhQTZ5tUvHQGyYIRMJpj5MTrq61N2a6ivtta86v9FrOA4av1iTRVRNdt1tocMEnPuGej726+O5VRgKMJRHQVKbTuPJxZIrSOtpyVcHLNpw1HqqiaRhTTocBq58BIQQTOjkUkGqYXsvrHyeWrQchOg6RyYgPGKXtz8XALUN2V0dJy2eWhG8HVPAouesFtB9VBeQLfmJ3UQgD2tjSo6SzhMCFYM2NdLkP5nHJZDHScgWOmNhy4IxeLKhchOUSrFxANnD1ns5v78ZkoqQHjEtUtlWIQyuEtIyi0metE3yLKXmuih1.qYFEjVaBfjUAHMaBjtA1wUxBU4qnwymfavAGRaBXpKBkDYQVuAuk.DfqVIfzktqDH5ugke3pqdWa3+9puscL2UwDbaAeeghd.e4uZwedwEV7UKZO3RsaOz0zWiT36SkCcYs2UNpMtLON3Dp7t1mQ7io8EDT+x1z4FOapahVWPPAuAmoNHjlRuqv2SaqzeeYO.J0rAe8rFaSTDsSIkGHWHUpXZ3XsM8LHpNwEs.daZTWkHDhquj+ChbDdw9DU4vIcdS5Bf8njOT6n3QLUuh4USPL1piLFabg3MvsXJ2NCGiyLDLBVp2GXLMy7Sw6ztM0UkCvYw698SaZ33e82N45uI1QIoj.F+TGRPHDtavvh3Tp0tJJJFN1EEaIo9BhmC6mJH1apUOFrQxxb+iZlqZy.QLuzckh7CogThBbyE1y0pc3gOVJhCGbWWrgIn3HITTFLEEUnC3TvVqJxZKoHJpMnNlyJp3RshkmpsU4bNjdFUFUl29wAf+lyo9vlwVV5rxHp1+xbaRTR1KKJs4VV8HhwGCcJLzqM.85CPeuAnu+.zOX.5GN.8ixosvki+VX7JY0jD1h.pXAIqyRixf0R3TtbQAQ6aiM3nPePGpRAtnnBx9bxYz1BYPAVCoGzbuuZKN63kO9VJP+weE1RcwWHCiNLsCcG9YPlKvQiwaB8MZSh8UYbKWEoofKB6H3L2x4IPb+omRkEw9PUnMUJHMMmyspcH0mRhJjn+k01iwoDY4z+IxVL4SzLT+0WfSfqstzm86he6CZX1H6RVYr5Rdkf2R144R.7sSmbTaQOlHYDtpuFX.ucp.I17TQr6KyZucaecVnvmH0SDjM44eiymxKTRCIR5QhV9jdKGYJocHn020N46nVTYcega2KOfXXh5XVc4SL809OGM8Jep021ro3qnriBSatOUctP103JS+FYMu1KMONTGhg1z2Wb9VhfPVZjF3TL7ZI76kUmvpRhDzz9lYMvwVy.WxSHQGQX9F2UbDLRr2AbGPXyrIVUNFZ.aN34wqtB7OHTceSgA7tDWPe60hn5ni40SYCY.T4Jt8yDxfYwXF8tyFaAaYFIPDDnUXS+xJElnNIBVSAAXynOvkvMhNVupKwGcr1CnwMRelZwqjBsDQUzfPwKh5wcQkv5sLXE7kqTPhoEhn7z7iHv7KpnzWGvotIdDi8pgm98Yv8BCz.O4B0hHgGuBeoWXdbhpjyUeHy1mBxdax3opadQiljWN.u0q4nngkm06hMb5ROOw.Tp8fw+bj1BfF3XtSMznu6K13x28pS3cuDtIzkiE5yfKYfyx9sAfgo7vkMQ.XA7Nb87QdnKcPS9sW62FT8+8W+5+bD290wOiqC7ndl45KbZW7CsuS8ZnBgxECbJEI+48ijyE3JKWaNrYBfLjgaFs9tR5ONIQ7XLwyabh0sJXvmerL3+5eMj3MDZTw5IGvkN5MiUh.nnsW+RIol8DzWxfuHFjryJZ9SfcdlRELdGU7gFmeEn3EgEptPzMfXZ87N+adL8OV+C5TaWO8Y61vsKUejOh4RXyCMs0+t.+eA0CEw5GSl8laL7vbGHCvkV7445ILRoWMK2vAlwvP7OveoKtV1a40KtV1hH2riBzszuMAiVUno0tgPWeJ7RohA1QvngZHA4dnjgJCf2LChlP.hdnPXF.56.o2S7TZuLr8DVJwqLqbr9fyVIk3Wz5dxOERFn2ElWJ4GiVgq9rHHGppj41s5drSjDYupaFBs4bMkLschCCERU0.iWUlNza08omaaL3R6myTcra.ylDUUvrOUR3dDupaF6wD5KJp5dBQXT0SjTR2UNmbFZ63ji2LvldwcxMNePbSADWo3Eo8hzNqqY3.tItwp.MOzz1qgNKoHDVOLIJf4wdgqqtRvWCgXCeOqOE64dSwdt+TrmGLE64gSwddzTrmuYj6Q+SzjV+W2xFXzZmjLKq7fmJn+EfC335A

Is there a way to get round the very short, seemingly "baked in" release time with the granulator? Regardless of envelope settings granulator has approx half a second of release, which isn't very much..

Love the granulator node, having lots of fun with it. I kind got round the polyphony thing by have 4 independent voices, still a little glitchy though :)

https://github.com/publicsamples/Oi-Grandad

Here's a simple 4 track looper (or something resembling one, anyway)..

HiseSnippet 4572.3oc6cs7aiijdujsKq1u5omY6DjAyEgf8PuYm3V7gjrwtHsZ+ZFiwtaEKO8NSNjdoEKYyXJRARJ2Val.LGWfEA4Z1aywbI.4ZtM4d9KHGB1+Dl+C5TOHEqhhzhTurZG5AXPy502i566q98UEYoFN1sPtt1NfBqed+tHPgMgM6a4c09WoYXAN9.b4v850t84HWOvd86p45hzAEJr7WPpuvZq.n+8SuXOMSMqVnvh.f2XazBchQGCuvRaT+qLLMORSGctQGtVqV+3V1V6aaZ2CyKKCKC5p05ZsKQuRizrkffuTy8JPg+Jnlhhd6pU2YW8VpUj1ssVM8VWnraEjtrpBZWjtdME8KZ2FTX0C0M7rcZ5o4gbAEVYOa89Mux9cVLB7FCWiKLQjGj.MwTlU7Q1l5DQjTJX+qLL0aDnjbAfBvFgprkYprmBO0P2XP4gptmPqnTXO3UfEVRj8VVf8j3YuxbrWLrTANVZEFK8wvlsbL55EVCge1.drkGxosFddhmUXsET3Gg6aiafk21cztFcjC9gAc3YUKW9yKoVt7u3W0tmUKOCaqR1Vux1C8Zqm8KV+eb80V+eZ8RQqpc6XqiPFGaSSjSrUSLMbtqN9Lqdct.474ktQyrGZPCwhunNElrNkeJuESp4Zns0wVFdutKxJICAfupBq++y74JL48nZ+OwW62zzPG4z.aHCLvJ5sfgEHAnrNlEKPL+007z.E9LnT0si+OF8xHQjCIxRCSjeI4+Uae7+6lWydliHKyHxi8Ixd877rsnDXMH6gARPnCehcmwRztWD9UV1WLTm+oWjEZKmAZGS2UlrtqNYcux3o3dL7LTqRmfrtz6pRRSgwPdJLFJSgw3NUmo2XWIQickJ+su7W19bkJU6ar2uo2qkL16Kxnwd0IaJu1j08cFWs7AHSs9kNv3FbYYviiaL1jLSwF.oIdDF1hqdFGggr2dRVGggr1JUG70Ge.wZAuTnePcbf9tHGOCxZHEN.cCFGCac00vpT2q8r6BJ7o6a2oqsEYIfBqmg392Nfz+1+g58G7vO1rd2fkWNlxxrwpzQeiDvk1+W1wtmkGur+NCcuqFTv22t9UHiKuJrIeuVcCOTm.XUqs5+5m992QpHrTY9hAbxzlYXYFNYpOmLAN+Njov9erkN5V15rSEAkJRe5+9+VDIkTJ3+hIn5n1Z8L8dieDCX4sqHH7ajhk+BEZfLmP+Ccivs0+sQ4Vvt2gdoqlCFxKF00wTpczEMwlaR.C2Ss6f4MMm9LUkG5VOxxomgbQdQDy+4ifuO57YQlHskOsNQ6BjIUhdDj9uSzxD7kiT8C9apyXmMgGb3Iu7aKc9wmdXlnNuMz22eLodQXiiOe+uTfvqMRjHbyi+ZdBC7UwXedm9O+2fUxobRChg8eKHJSdPTyBTcd9bqT.5IAKt5clhVbqRBUln415jZsczw.Pt3xP6sO6yd+6iwYC79tApQ9RACYatUJfrwYenOSEd4QJ7xyYgWkS365NSEdkQJ7JyYguBmv+Ce2LU3UGovqNUE90SKXeNGeI9kZbRq3QA.wFNIPGaLZvBa.OGg4jl8sZA5nIDZw0C0sowuS.pWGCccSTCaWCRp3g07WVeLjHADC5ODjH93S0ceHHQBAc9tEZIZiLjjXBqgdmPUm.TowfxUIR7hB+OWDGl7fhyBJJAwSgS799uH8nnvvWN9axHZ3pIs77LAMr7jiFdiTjydBK5NSDIk4gHsSRKkNSDI0otHk7davsbx07d0+zKRISuAY77GrTfbui3geHDIqLWjLHTZ6xoyE9IP0Rm6fCTT5DaxtOvIS+3uiWl94QXme7hXbkaaa4IFLUsd5zrB63CmXsCGO7m5kdiA1nIMRsJ3ueBzpajtse5V94vIQbjW.DG9f8+GtSj3nr.HN73M9Se2DINpy.wY3yX6IvSs06Yp4IdjejCF0uBBjE9yYibXZVXnLBAnlZmCXZYwOF1vvq0UwyiKECOB.yDdz+zS2BdX61nVdgL3Jvi9l4vQkBYzeceyILMIDWv5hmIdUuNgf4HmsXAh5I3nS+8vviorqCBaVhN2tAdEpm4p0oqI5LLm+4ktvzt00DypgOaSeS78Hs3YstRyxBY5NNGA5poVWIc2SUmY2yyv5xS07bLv9FPhB.uVcKz99bWvQs3+b4fCyrIxRm9v6w+4WoD44B9UJETY3gnBdEx6c1NWSmj7+23EKIyHEYK0CdCxwklDPQX4sw+G3kll1uiDlwv2NFOKQKqgsY+tWYaYzhTDqEAbc.JdFq+kZtmqYXRL7a1ysKl2dsUSbiouICDCuWQyZo3QZsv5z9MzHwP9XH4.iwVqHmsaMvpMfMCsYH5U1quPPcj4gFAQrbYyADJDfBho+vLbGZbykf3lPpmnU7YkUIzZM3ss0vlhx.AF6ITFCabrMq5X4kv9NJJycJH3R7eBGWXIBK7QD6ANYweqzWFJScx4a5pjnPnfVfSUAq4zbvlBuiDG5bMmKQdTRvWf+owXgn18thO5qMNltKtWhmA1AzPb2bnudJfwe.2M9AjSfIASBdBq+N0vh6zDJCNU61AOSV.gYhvJ5k87r6fcO8eKSNf+vH..t44GAc6ZZ3IARz9iVeryyC563Xf8HH0vtBXDF9wSX+9lVBWfivASmBzcCLccPaeYRTLnSiffKIL6sL2rWwvYuGA+qkJGcBj7byAHBdJ9Yban+IotaYIop3PoWidGioAE9YvJaqJKKWqbsZp6nJoTdW.yQfZEwM8WXoHS9wyTQModDjP+rwTjFnTVprBtA6t6Np6Vqrj+aETyN11dWgi0G3itJTlL5B7VPgf4udaSVBirgUXvOXnywq7fvOz3VBdrB0PwBvGlZS3wtugTaKMy.pfWjXXuB0IvqPM0dEqxQ30gcr0Yis.oeJGoGzh3nN2.LNdk9wRjmf3PxolvqLrFemIPiuyXow2D5Q1mx25R1nxXz4jEY4ZQbzWXHFEODhFOb8v3WeZUH1ftq3xSaBafbLr0ouSkhKRsBm65pIGQYUnzNBNq7qZQ2x1zF1RfHRQIR0DHxlvSwCmA1RAOFQ8pIMRf5fzITrdFG4VCdnkFFFrNPnowGNIUzJsgjIT+wvu1hXUfXSX9iPQb70gioETpXTMgXCNjfiD9SvN8SFXmNndgzY7iKLnxrfFDLYlqj0A8P2AZpGEpmCSBMTWGl7bygNy.fvJJgsjG+0PCsnJOrbQiNNktuTEGJEZECqo86wHzxqLJsLcaULQ2F7BKcfAN5pVexqnsuZTnDxRarycfkv0g3bF00Q5ztGjDVhvhhNM7C+w+3+4KFZZn9+R8HSCz1k7zfPzpH57usd7yEea8DC.Tb1XrrAjrOr3znc7.CMTIYv.l8Fw9NOojk9oWjnM7ZDLAu0v5FQy3GCws9psCpaXK4v9MR71IADSvYu3BhydD+abjrn92TECshX8uIU7PVkzEoccrg7nUDmJgVwjFxKwEVn4CFaZ5y3fjS0jJViASUZ9iw8wb.TkjWrP4VjtbYkbXt4vbYFqaL.oZkERbtwZv9gOP2.wJGoaNR2OXQ5td.h0J4PcGBWWQJv0J4XcEzIDjqUVb.6xNgCkGNncqc+h1UZQDsqZNZ2bztQQ6pt.i1U8gIZW0bzt4nce.f1UMGsaBncUyQ6NDZW0EMztxObP6V89Esa4EQztJ4ncyQ6FEsqxBLZWkGlncUxQ6li18A.ZWkbztIf1UIGs6PncUVzP6J8AJZ2DGfoJP5sfruA+KzrtNw2TgvlDKZVwwXDSlv6jgS7ieQc3upkUF+OBE0o8W0Rko8.VcZOf0Rka.+GhmvigN.j6YAQy+fK9x1zK9xcIW7kJul87z5C6YzHwiCLjvqcNmQ73YlKLDK1V4awkeYDSyfL1.S53pNiF2ZynwsZBi633ATNNOf+Nyu8ncWb8.3iRK8v2EXMLbqtjtINs+QvyXE6C.ZrLqVOXrUmkCtxrbvkGwfONdERe.5UTj8QTMNe+UAccb97qJBi4iNKc6dYPWSKYgBupwWNDUG02.peex+DPy+DPGwGKUKjwMng9jpcX21Aa6WeBe57A0lIyrLG1Xc3QHj9Ej3V28mJdRh4lv1F2tyaoW2DhB5eNmyKWaheUTtFjwuZzhrcnNXsMAV3mwwBAMHIsMq1I4ZSnvveMoSx6dT0w5yoWDn63cXLhfZG4NcOaN.k3b1R2wZLSNFE5OMCS8CRIocibw5vTR+FLQcjeqN4FHIxtLsA6dIw+L2tqfIAcen6aD7ZxCpNV61MB6d1Batz8xBggJjn5c1Zaim0GgIkUSv.DGtO32CmADqhjbLS8rRmxayVhJ8HxSEAuIBiDUkVEuZs7t0ptS4cpnVa2Z.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.WxsohIxnx2KLpb1YTk6EFUI6Lp57jQCyTOM7YwAa0xAF2XfAlmLmFvbkqORXLh6tG20VYrWQkQkqUx5kelvtTBx5UbVF6csIp2UuqdGcdYMRPO77BeniP0VJlY.0mtyLYcIzzIdxYU7RNN9zVztqUYSmvoLtycSaupruXb5DP0OfDvx2o.NFoKtms80czbHWeZfu93fqUMLi3gr73FvBEN.ciQKz486R2L0CPtWiWXfRzVHWWZ9vrJ2B9xd5F1jqgZLWQn8SYkThTToFlZ8QNRBuguz8YfoYp++17+9E6oYpY0RX8j2Xio9IFcL7BKsa8uxvzbvFdOnb05G2x1JXqUHa7RSrx6T511Dp9aPul5bvKnP1JANRQXyfCwgq8mYa68JaOtwnQ8lZjqiN5ssMd34GjyP2fyzFIT1QFlH1V.80vmehwENZN8e9K6hm9ZQ2q1RM60sqsi2y6POMFGW5n69baiRW5nYoqoe6sOmpJIij6yILp6yuvAoc81uS6FPGhVjsSRczn2Ive0e3I.yA2G390YRkO8f5Kr7g5FXSSba7HyzqrmsdexIlZwNVh2X3Zf0ErGZhUpLU5Q1l5CN4h8uxvTefo.6HCCMLVlYX7T3oF5FCJee5QkRrOdBshRg8f21nvRol8JmZ1i2rcEF2gYB1YfIxYDSyvCGSfyH6ytkqAwEiyoNB6tb5X2XzfE33w0B3wlFDShCstAYhcun73m.8CCETpnu0o1V1cux1xnkn4omiwkWhDupsiSfdomG89TLnjmV+LjIRykyO3mW+DCKjlSTOrLnKjRut3tlu9KfL1sDIfPoIYdatZl8wPZvnzyujypZFyuKGDM+v1swKJExrq.O5alCdnmwNovS0vFpjXYupWml334sPXNAuLooKI90RjMMm8b4fvaMQV5kCt7y8qTh7bA+JkFbynOOnQGsVN1u0+czfXK+HZIX41x+sT4Txykj.2DMGpN3nhusUKwgZnNJOtcTYb6n531wJiaGqNtcr131wcFcGIKZ4e3HDWV.3zFGxtgYKL.9PgkA+evc0qz1

In essence, it's just 4 tempo synced delays with the feedback set to max and a gate controlling the input gain of each delay. This acts as kind of record button.

The controls:

Dry/wet - obvious
Mix - the level of the delay channels
Delay Time - Set's the delay time. Adjusting this after recording has finished gets glitchy fast .
Pitch - controls pitch via a repitch container
Record 1-4 - Opens the gate allowing the input signal to be captured
Reset 1-4 - Sets feedback to 0 clearing the "recording" (hold until fully clear) *
Record length/Divide - Sets the duration of the record gate

I'm not clear on what the exact applications of this are yet (Do people use loopers in DAWs?) It's hard to get the timing right when hitting the record button (switching the ramp controlling input gain with a. clocked ramp would make this easier when working in a DAW) , I've started a project using similar techniques here, this applies a modulated xfader to the input and and output allowing it to act as kind of buffer glitcher/remixer thing. . Again, it's kind of cool, just not sure how to translate that into a meaningful end user experience.. suggestions welcome!

Scriptnodes File player has a curious mode called "signal in". As far as I can tell It derives pitch and trigger from an incoming audio signal. It seems the most obvious purpose is for drum triggering, however if you run an audio rate signal into it and reduce the gain levels it produces all kinds of funky wave shaping, folding & sync-like effects. Further, with the addition of a simple add node, we can specify the start position allowing for a tape scrub effect.

HiseSnippet 3116.3oc6b0DaaibEdjkGaYGGmeaQts5vhhDfrJjTT+kdvJ+XuwHwIJVYS2zKAzjirHLEIKIUh8tXAxkEn.sE6stHGB1.zBzdrnmZOUCTfBTfcurKPAJJZw1KsG5kbuGRmeHklQRTlTw1wMHJGVyY37deu27du48djba34ni78c7.Yl6d63h.YV.1bG6f1WqsloMX0qCxLMDsM3p63p46iL.Yxj88IyjYtoAzeuXoqpYoYqi5OD.beGSczsL6XFzezF0uook0JZFn6Y1g6tUqupti80brb5hQQVnDvUSeKsMQ2VibaSAAYlYYCy.GulAZAHeLhtpiwNMa67Xa18eeSeyMrPjKjAMwDhM7JNVFDDSFEbs1lVFMhjVe.HCrQeYOKS1OKbMSCydi2WGbR5D46uBd8QloDgWVA3IyCOIN3MBHkgCRSyfzofM08LcC5OCAOGCtpc.xqkFVsyCE18BxrK7ZN3avNnPGssPq3gun2BNeYIoKlWUR5Be+Vcs0CLcry6Xeam.zcrO+El+imet4+j4yO3TsZMx4HrwywxB4MxoI6zdiagm2tamMPdWL+izr5h5ciXwWTmBiWmxukqyjZtazwdUayf63hriyP.Dppv5+4CQE1hKfp8+NgZ+qz0vz4Gn8HTKGuN.SChEgvXx.p.v6CXnEnQMe8zr2DgEDO7FCLCYJ5HKaaDcMnGeyx36hg7sokoAxixvYg2z1YCQ97s2828OVJ4KVYPP9hTr3hBKN+O6o+4+PxWr5.bt9Cqm7EWRXwO+K+xKraxWb4A37O9aRAmqNvhuwmkhEWSD1O8o+0Dosyw1mkFbu5j0AevpWmXSgczCMYwlwtHu.ShGRlqidDNnKKpwbvqi72JvwkZS2w0wlXfmY1TaUucO.35WeG9f1O1zHnMw.dQrIbaj4lsol20wW4F4csJljmKjY1NFn7jiVP9l9HOhmXefkaOM66CDv6xCj2sdx3lqlG93DbHvUoD0usFlgAnswL+33fotcCx2jNVGssET5Cq9Fi+ULnb26MInDB6XtcHFg3Cf1VPkc78zeMFv7D8IALK.2DeXnSqV9nfd5MRl.4uCarN3kyL7zM2.YA5vmjvC1UPsB.9AH2lleDm2wueI+tsZgERrrl23p30aXXgZ33aRNwn+ZU1MMZAUdsfwjX3vj0Yfq3g9QhpjYfsHiwD7iQugtHa8cDEc057hNN7y.hNMLLmneiOJNQ28yqmFQuTbh9jYMNC0.nm5flD3Qy87xwI3I1xmIjSCuUCQcvzPK2ir62UiM5iUJE6aLjX290mXmaOOlsOa2ke294oSrmkLc2MF5fB5fwYX9sKwC0426C041hJvg0eiWpvZNXyNNN3ieE.aNnOaT9ch5ewH2IhSfdPcvv0ffq9wwnqkVfXIQjP.gSPnAecHjhMrwzdGddNXcRSmr5jFeYbIEtmB1vLPu8nw6Ti.u3zrNnwaXUmGGtbqVH8.9RtW4CGaIl66PY9HnDZ5RZA.EJwZIFSGAdxe+68GSZGAbSbGAtc2NzDSWwzhVMXFRYSQE6dQXZJrblDqISQuDl4HWuDN7bi2eZ2wbQXroYGWKbwwOBYgKtghwSiSvnkVWqfnQEs9Vyw1wssisoNuA25n.OyM2D4wi8QJPWIHPSeq9ib15qirPZ9H9iSukoMRyaMVBOShtPN0s9Yj6WmCxfadhKS9WK6a6KgbylnPt6KXbxCydfqhxAWd6.OM4if6dgPS4vDZq6zMvzdy0zvttjzDwg8ahOCPGggksMxhF5eJR+xXWKE0.slHaC5EuD+KbR4dmSfmTNZx9c6CbaTvic71h58E923L9XxNs+.dfqXY473FNV6DEegJOHOeZRSyBkJf+G6tH4AZFZmi0TrKi.9U53z0NHB82Py+dZlVjDOZ102ECu6X2DeyziLIVg2lFlYlUzzwp0cZnQZzxofjlah2cPdEz41kBQZ+cIpVFq8aDkanOC1DhFclJSqgwXGZhqjdrmkLOQWjkwcHg7K.c70wmQSLM.CAGOTAtoEQvdwMh9wBscTCsttouqk1NWEWf.hEOTXD70qZaf1l3y9d3Sf4jMxguQWgY0Zl12m03LHY2Arl118tVEecydICCgx3qIR4LPZb8qzMvoC1DN5XdNxNSexNCTQjtygG.+Sf1mEyaYI1OY0ZRxxkww+2B8XlNjcCJJ0pIoVprhRQ0pUpVJry98KvZL.RPNkEvyLP4xwHnKPId90IVo.gkCRpNTNVc36iQZ7Dc58hnDhLKrQax4tQZ1oW789sO6R+5uYoTSovFTziPu3W8mtYE3uXI.WKSA.NK8bvsaoQJWSvJ+jTmNb5jEBmMcF47LKyTgWgicNEgimfDdiyPNDqYgJ.v.2ZnAZ3cjCxRFAGY6wjCXuml2ln.JK3GHrOw1HZlw9hWBXAY3ZrSCwl8PUefIgdyRom7nInfialzaevFZPGCt8QbE6tV3hLhM1Ia5zsOFEZbJAFwhBuGAomLFkgiQg6OB74XrnualZNLkvFP1QGhKGNFqzf6AoL.2YfkJnpnnTQpRE0ppxEkpw6XxsChORbzvXP6fbP4IJNaQIYoh3anVspp0pHIGFmk0BEb5FQ9UmApnVpPUBsJVtLF4kTi6PfCRMzBv0Q9n.FYEHtXvK9cRgYn0RvG9XA3p92mLqtlUDEwZcgneTqU4CFq44EbaHFsEey0bdLoNb3aPKKqTnLkVkqToJF7GkMnGxJQ4sVIGJVIEKUqPEBsJg+qZpUJ++IVIyCcrQOz0AWaofgxogsLsH61E5M+qTwIqvnV++jDWkqbjk6rAxv.Yb8n23iDUex3Jj3foRgyPsJXaMx0TjpoTii8mAVqP0ZjekkqVpnjRkhCCjxpUjqTUtRQoxkjqVlBjrv6BFCGhI28YwZtpCV3R0Ql9djYPZJQYBcF9tDpIUi8qRkxpUUJUUY+n7H9L3mDAZDDcN3x1ZaXg20GnrqX7WNVO+E425vbTwgQs.9vYLNKJoh+ukTqtO3vbRX4BEkqnHUEatWrRo2r7cjec36LGz2bSkNNFhdNKBwVQsKDMG+yTLUIkLwkB2qCG+7q8Sr92Ye935vAszW4jWZLKC9j1fCvnpRNrvBkjWXQ5XZZp0YnhlFFmEOhfyAZBa.piqyC82wVWDemsW6o3tiId+q+CpoeGkhqkQXsnqXGdV.1.4Y5XPeTthwymdzYS1+w9vERO5M9odyQ7VKvGYh6g5QcGtGQC.Fhzfwy6Wrzv7VJk7dA3ZcsBLwNOXlLD8AoW3wLKU.XnXYuJbu9mMn3SeQshm6KB+.ahgGhs0O.GLqCD5kE0vYTk0QmHE1tSuW1tfz9HFhRQg8fhDyQI7gGEagjyNftkpyd00sBNUbzJnZwreZ8jzDszZmA.wiliAukiiK6MYOsNZ6G7W7YLvYjK1VVKRuwELwVfcJMalTXiMUrMbS3.6CHwcni3GVUOtizfPMiAxVYdldfL99uVX1CIsvO8ysOc1a70KIZ8KzV.16A2fOLmSvBzzax8GUvToVET+KRVTf7e0y9pkXOond4ZOTH1KWr3+coC6.AKF8B4DmAJ2twwI0VhKpDGncvMjSy1P3m+UprStWQL9qvmUDFYmPSw35mC9we3C9gW9xM0HTZMM2O4Z6nbmFUA8UbjEwkAdlg7.ExuYrEinDSwHKBafE+Mzz25.nRmT7jYGpB6bzJrCIzIfqisB6WCcu5RUUSU6LD0BwT0X+B1G4Sqdr8MV9sOrrC7tFGZp7l7yGKVBH58OGuuD6fWx2syd4pJbQxdx58dGEZH9NpyHkvVA2CN9feWoW7+SB.+xW9x2Y2z7hBnrGun.gBiv2ezgnHkC.9Ku7kWJUhTw8TjfrW+PKWv9S6Mu+feiiICtbO.EADy2ozQ.61GLvFnlPXy2G6ji6nO5uz9FhMTtRICjBu5bCXOPOkeD9qzumrCkW0rdBEtp1m8zmd+5upBUbp9YBU8zOil8+rQ6sz24S+O2c6K8OS3lCq1njEFs2mUy9ex8BK8I+q+1RI0ssWMLBhvf0ILQm5cUGms5nQesXmnO33CkWh2NZ5dNOLr4mDgKGcDbRZ1z+mFwbv0HWmeDeV9cLMLenttHoFZgJS5BKNoKTcRWXoIcgkmzEVYRWX08dgjuMlv7cIF8XOrFKyJUKSTSNwkqC9eTelmlB

For sync and fold like effects, put a harmonically rich sample into the audio waveform and tweak the gain levels. Adjusting the highpass filter can sound an akin to PWM in some cases.

For tape effects, load a loop, turn up the smoothing and tweak the scrub knob (try modulating a this with an LFO for interesting, glitchy drums).

@d-healey I notice it quite a bit with synthesised samples too, hence my interest, even more annoying is the tendency for crossfaded sounds to have volume dip between layers. Smoothing helps a bit (smoothed parameter in low pass mode in particular) but it's always there to some extent.

It's a shame physical modelling (of real instruments) never really fulfilled it's promise, but then many of us might not be here, or maybe we'd be talking about HIPME.

@clevername27 Nice, that ring is really pleasing. This is kind of attention to detail that I aspire to.

Just gonna throw this into the mix:

Design and Run Real-time Spectral Processing on the Web with Faust
https://inria.hal.science/hal-04507625/document

And to rewind a bit, what about an equal power crossfade? Shouldn't that be a bit more forgiving when using material that' s not been phase aligned? I used to do this all the time in Logics EXS24 and the equal power fade was almost always the way to go.

Excuse my naivety on the subject, but In scriptnode alone we have the ability record, analyse and import wavs, generate sine waves and have extremely large sliderpacks (if I recall, this was bumped up to something like 4000+ in a recent update). All the important stuff needed for spectral resynthesis, no?

@clevername27 Cool, hadn't thought of that.. Got me thinking, I wonder if it's possible to give a table envelope a release stage somehow, maybe by inverting a gate signal to activate a standard envelope on note off?

@clevername27 The ramp node has a loop start parameter, set it to 1.0 and it will one shot.

Here's a simple 4 track looper (or something resembling one, anyway)..

HiseSnippet 4572.3oc6cs7aiijdujsKq1u5omY6DjAyEgf8PuYm3V7gjrwtHsZ+ZFiwtaEKO8NSNjdoEKYyXJRARJ2Val.LGWfEA4Z1aywbI.4ZtM4d9KHGB1+Dl+C5TOHEqhhzhTurZG5AXPy502i566q98UEYoFN1sPtt1NfBqed+tHPgMgM6a4c09WoYXAN9.b4v850t84HWOvd86p45hzAEJr7WPpuvZq.n+8SuXOMSMqVnvh.f2XazBchQGCuvRaT+qLLMORSGctQGtVqV+3V1V6aaZ2CyKKCKC5p05ZsKQuRizrkffuTy8JPg+Jnlhhd6pU2YW8VpUj1ssVM8VWnraEjtrpBZWjtdME8KZ2FTX0C0M7rcZ5o4gbAEVYOa89Mux9cVLB7FCWiKLQjGj.MwTlU7Q1l5DQjTJX+qLL0aDnjbAfBvFgprkYprmBO0P2XP4gptmPqnTXO3UfEVRj8VVf8j3YuxbrWLrTANVZEFK8wvlsbL55EVCge1.drkGxosFddhmUXsET3Gg6aiafk21cztFcjC9gAc3YUKW9yKoVt7u3W0tmUKOCaqR1Vux1C8Zqm8KV+eb80V+eZ8RQqpc6XqiPFGaSSjSrUSLMbtqN9Lqdct.474ktQyrGZPCwhunNElrNkeJuESp4Zns0wVFdutKxJICAfupBq++y74JL48nZ+OwW62zzPG4z.aHCLvJ5sfgEHAnrNlEKPL+007z.E9LnT0si+OF8xHQjCIxRCSjeI4+Uae7+6lWydliHKyHxi8Ixd877rsnDXMH6gARPnCehcmwRztWD9UV1WLTm+oWjEZKmAZGS2UlrtqNYcux3o3dL7LTqRmfrtz6pRRSgwPdJLFJSgw3NUmo2XWIQickJ+su7W19bkJU6ar2uo2qkL16Kxnwd0IaJu1j08cFWs7AHSs9kNv3FbYYviiaL1jLSwF.oIdDF1hqdFGggr2dRVGggr1JUG70Ge.wZAuTnePcbf9tHGOCxZHEN.cCFGCac00vpT2q8r6BJ7o6a2oqsEYIfBqmg392Nfz+1+g58G7vO1rd2fkWNlxxrwpzQeiDvk1+W1wtmkGur+NCcuqFTv22t9UHiKuJrIeuVcCOTm.XUqs5+5m992QpHrTY9hAbxzlYXYFNYpOmLAN+Njov9erkN5V15rSEAkJRe5+9+VDIkTJ3+hIn5n1Z8L8dieDCX4sqHH7ajhk+BEZfLmP+Ccivs0+sQ4Vvt2gdoqlCFxKF00wTpczEMwlaR.C2Ss6f4MMm9LUkG5VOxxomgbQdQDy+4ifuO57YQlHskOsNQ6BjIUhdDj9uSzxD7kiT8C9apyXmMgGb3Iu7aKc9wmdXlnNuMz22eLodQXiiOe+uTfvqMRjHbyi+ZdBC7UwXedm9O+2fUxobRChg8eKHJSdPTyBTcd9bqT.5IAKt5clhVbqRBUln415jZsczw.Pt3xP6sO6yd+6iwYC79tApQ9RACYatUJfrwYenOSEd4QJ7xyYgWkS365NSEdkQJ7JyYguBmv+Ce2LU3UGovqNUE90SKXeNGeI9kZbRq3QA.wFNIPGaLZvBa.OGg4jl8sZA5nIDZw0C0sowuS.pWGCccSTCaWCRp3g07WVeLjHADC5ODjH93S0ceHHQBAc9tEZIZiLjjXBqgdmPUm.TowfxUIR7hB+OWDGl7fhyBJJAwSgS799uH8nnvvWN9axHZ3pIs77LAMr7jiFdiTjydBK5NSDIk4gHsSRKkNSDI0otHk7davsbx07d0+zKRISuAY77GrTfbui3geHDIqLWjLHTZ6xoyE9IP0Rm6fCTT5DaxtOvIS+3uiWl94QXme7hXbkaaa4IFLUsd5zrB63CmXsCGO7m5kdiA1nIMRsJ3ueBzpajtse5V94vIQbjW.DG9f8+GtSj3nr.HN73M9Se2DINpy.wY3yX6IvSs06Yp4IdjejCF0uBBjE9yYibXZVXnLBAnlZmCXZYwOF1vvq0UwyiKECOB.yDdz+zS2BdX61nVdgL3Jvi9l4vQkBYzeceyILMIDWv5hmIdUuNgf4HmsXAh5I3nS+8vviorqCBaVhN2tAdEpm4p0oqI5LLm+4ktvzt00DypgOaSeS78Hs3YstRyxBY5NNGA5poVWIc2SUmY2yyv5xS07bLv9FPhB.uVcKz99bWvQs3+b4fCyrIxRm9v6w+4WoD44B9UJETY3gnBdEx6c1NWSmj7+23EKIyHEYK0CdCxwklDPQX4sw+G3kll1uiDlwv2NFOKQKqgsY+tWYaYzhTDqEAbc.JdFq+kZtmqYXRL7a1ysKl2dsUSbiouICDCuWQyZo3QZsv5z9MzHwP9XH4.iwVqHmsaMvpMfMCsYH5U1quPPcj4gFAQrbYyADJDfBho+vLbGZbykf3lPpmnU7YkUIzZM3ss0vlhx.AF6ITFCabrMq5X4kv9NJJycJH3R7eBGWXIBK7QD6ANYweqzWFJScx4a5pjnPnfVfSUAq4zbvlBuiDG5bMmKQdTRvWf+owXgn18thO5qMNltKtWhmA1AzPb2bnudJfwe.2M9AjSfIASBdBq+N0vh6zDJCNU61AOSV.gYhvJ5k87r6fcO8eKSNf+vH..t44GAc6ZZ3IARz9iVeryyC563Xf8HH0vtBXDF9wSX+9lVBWfivASmBzcCLccPaeYRTLnSiffKIL6sL2rWwvYuGA+qkJGcBj7byAHBdJ9Yban+IotaYIop3PoWidGioAE9YvJaqJKKWqbsZp6nJoTdW.yQfZEwM8WXoHS9wyTQModDjP+rwTjFnTVprBtA6t6Np6Vqrj+aETyN11dWgi0G3itJTlL5B7VPgf4udaSVBirgUXvOXnywq7fvOz3VBdrB0PwBvGlZS3wtugTaKMy.pfWjXXuB0IvqPM0dEqxQ30gcr0Yis.oeJGoGzh3nN2.LNdk9wRjmf3PxolvqLrFemIPiuyXow2D5Q1mx25R1nxXz4jEY4ZQbzWXHFEODhFOb8v3WeZUH1ftq3xSaBafbLr0ouSkhKRsBm65pIGQYUnzNBNq7qZQ2x1zF1RfHRQIR0DHxlvSwCmA1RAOFQ8pIMRf5fzITrdFG4VCdnkFFFrNPnowGNIUzJsgjIT+wvu1hXUfXSX9iPQb70gioETpXTMgXCNjfiD9SvN8SFXmNndgzY7iKLnxrfFDLYlqj0A8P2AZpGEpmCSBMTWGl7bygNy.fvJJgsjG+0PCsnJOrbQiNNktuTEGJEZECqo86wHzxqLJsLcaULQ2F7BKcfAN5pVexqnsuZTnDxRarycfkv0g3bF00Q5ztGjDVhvhhNM7C+w+3+4KFZZn9+R8HSCz1k7zfPzpH57usd7yEea8DC.Tb1XrrAjrOr3znc7.CMTIYv.l8Fw9NOojk9oWjnM7ZDLAu0v5FQy3GCws9psCpaXK4v9MR71IADSvYu3BhydD+abjrn92TECshX8uIU7PVkzEoccrg7nUDmJgVwjFxKwEVn4CFaZ5y3fjS0jJViASUZ9iw8wb.TkjWrP4VjtbYkbXt4vbYFqaL.oZkERbtwZv9gOP2.wJGoaNR2OXQ5td.h0J4PcGBWWQJv0J4XcEzIDjqUVb.6xNgCkGNncqc+h1UZQDsqZNZ2bztQQ6pt.i1U8gIZW0bzt4nce.f1UMGsaBncUyQ6NDZW0EMztxObP6V89Esa4EQztJ4ncyQ6FEsqxBLZWkGlncUxQ6li18A.ZWkbztIf1UIGs6PncUVzP6J8AJZ2DGfoJP5sfruA+KzrtNw2TgvlDKZVwwXDSlv6jgS7ieQc3upkUF+OBE0o8W0Rko8.VcZOf0Rka.+GhmvigN.j6YAQy+fK9x1zK9xcIW7kJul87z5C6YzHwiCLjvqcNmQ73YlKLDK1V4awkeYDSyfL1.S53pNiF2ZynwsZBi633ATNNOf+Nyu8ncWb8.3iRK8v2EXMLbqtjtINs+QvyXE6C.ZrLqVOXrUmkCtxrbvkGwfONdERe.5UTj8QTMNe+UAccb97qJBi4iNKc6dYPWSKYgBupwWNDUG02.peex+DPy+DPGwGKUKjwMng9jpcX21Aa6WeBe57A0lIyrLG1Xc3QHj9Ej3V28mJdRh4lv1F2tyaoW2DhB5eNmyKWaheUTtFjwuZzhrcnNXsMAV3mwwBAMHIsMq1I4ZSnvveMoSx6dT0w5yoWDn63cXLhfZG4NcOaN.k3b1R2wZLSNFE5OMCS8CRIocibw5vTR+FLQcjeqN4FHIxtLsA6dIw+L2tqfIAcen6aD7ZxCpNV61MB6d1Batz8xBggJjn5c1Zaim0GgIkUSv.DGtO32CmADqhjbLS8rRmxayVhJ8HxSEAuIBiDUkVEuZs7t0ptS4cpnVa2Z.VJThX1mdmLpbB5yOh8ybSWa+qEHgNLR3BS7FeNFauIFiN8ZQJxIXDfIgTYBfdoUkkMqOFtiKngO2wASRTNG5lZQcbtoVTygomCSedbSsnLOxbc4gbJTxScM2mXZm55Vboiod+kTG2lJtfjUWvKYm7bIstUha2DjePuaBhYddul8ZwIJ60Q57kmJ6GNoxJOYoxJmmJ6BWprCkQj7hWFQxfY3KPSd522Soee4vW1ooKU1J4v1ygsOORkU99IUV47TYy8IlkoxpjwTYCdmbmdIxprnkHqx8WhrJ++lDYqkmHadhrKDIxpLYIxpjmH6hehrJKdIxpjmH6CzDYqNNIxVMGzdNn84QhrR2OIxJkmHatOwrLQV446YxJ9yAVPBXOPydSLgc46yD1i4WIqp2quOwUySjMOQ16uDY4SkL64wx267zXev8pEK7McQymcQIM3vU8RNK3GxIwlzclwBUhr0FmDYqkCZOGz9r8qj3N1rO1ucrigY6t4ls4lsySyVAyoOIqYyAws51zgoMsWDBA+rTG49uv21hmAYVimgZIAFEuNxk6jRMGxcOClAVTddxh7+H4jAdT49gGUyBOpd+viJilGWMvIu0IHqK8t5tLJSHk3oHqKbmsF+UIycv6xiMuGeDszy2Q9wHKybtxDv4RSONWJ6bt5hAmWdzbNjsiFGcQSO6thl4Rwr14TN1q+Gjn.WxsohIxnx2KLpb1YTk6EFUI6Lp57jQCyTOM7YwAa0xAF2XfAlmLmFvbkqORXLh6tG20VYrWQkQkqUx5kelvtTBx5UbVF6csIp2UuqdGcdYMRPO77BeniP0VJlY.0mtyLYcIzzIdxYU7RNN9zVztqUYSmvoLtycSaupruXb5DP0OfDvx2o.NFoKtms80czbHWeZfu93fqUMLi3gr73FvBEN.ciQKz486R2L0CPtWiWXfRzVHWWZ9vrJ2B9xd5F1jqgZLWQn8SYkThTToFlZ8QNRBuguz8YfoYp++17+9E6oYpY0RX8j2Xio9IFcL7BKsa8uxvzbvFdOnb05G2x1JXqUHa7RSrx6T511Dp9aPul5bvKnP1JANRQXyfCwgq8mYa68JaOtwnQ8lZjqiN5ssMd34GjyP2fyzFIT1QFlH1V.80vmehwENZN8e9K6hm9ZQ2q1RM60sqsi2y6POMFGW5n69baiRW5nYoqoe6sOmpJIij6yILp6yuvAoc81uS6FPGhVjsSRczn2Ive0e3I.yA2G390YRkO8f5Kr7g5FXSSba7HyzqrmsdexIlZwNVh2X3Zf0ErGZhUpLU5Q1l5CN4h8uxvTefo.6HCCMLVlYX7T3oF5FCJee5QkRrOdBshRg8f21nvRol8JmZ1i2rcEF2gYB1YfIxYDSyvCGSfyH6ytkqAwEiyoNB6tb5X2XzfE33w0B3wlFDShCstAYhcun73m.8CCETpnu0o1V1cux1xnkn4omiwkWhDupsiSfdomG89TLnjmV+LjIRykyO3mW+DCKjlSTOrLnKjRut3tlu9KfL1sDIfPoIYdatZl8wPZvnzyujypZFyuKGDM+v1swKJExrq.O5alCdnmwNovS0vFpjXYupWml334sPXNAuLooKI90RjMMm8b4fvaMQV5kCt7y8qTh7bA+JkFbynOOnQGsVN1u0+czfXK+HZIX41x+sT4Txykj.2DMGpN3nhusUKwgZnNJOtcTYb6n531wJiaGqNtcr131wcFcGIKZ4e3HDWV.3zFGxtgYKL.9PgkA+evc0qz1

In essence, it's just 4 tempo synced delays with the feedback set to max and a gate controlling the input gain of each delay. This acts as kind of record button.

The controls:

Dry/wet - obvious
Mix - the level of the delay channels
Delay Time - Set's the delay time. Adjusting this after recording has finished gets glitchy fast .
Pitch - controls pitch via a repitch container
Record 1-4 - Opens the gate allowing the input signal to be captured
Reset 1-4 - Sets feedback to 0 clearing the "recording" (hold until fully clear) *
Record length/Divide - Sets the duration of the record gate

I'm not clear on what the exact applications of this are yet (Do people use loopers in DAWs?) It's hard to get the timing right when hitting the record button (switching the ramp controlling input gain with a. clocked ramp would make this easier when working in a DAW) , I've started a project using similar techniques here, this applies a modulated xfader to the input and and output allowing it to act as kind of buffer glitcher/remixer thing. . Again, it's kind of cool, just not sure how to translate that into a meaningful end user experience.. suggestions welcome!

I ran into something similar recently, Disabling ShowTextBox in the property editor fixed it. Since I had a lot of sliders to fix, doing a find and replace in the desktop.xml file was quicker.

So, showTextBox="1" was replaced with showTextBox="0".

@Lindon said in Sends as FM source/carriers....:

a script node to combine(multiply) two signals together...

This perhaps..

https://docs.hise.dev/scriptnode/list/control/blend.html

Wouldn't using the send/receive system be generating a monophonic signal? AFIAK your carrier would be getting the summed output of all active voices, rather than per note modulation.

@LozPetts You need to define an Audio file slot within your network, see the little waveform symbol next the the samplemap list? this allows you to create a new slot that can then be called with the const slot declaration in your script:

Cool company name, BTW. I once knew a girl who could recite The Raven from heart..

@LozPetts Samplemaps are handled a bit differently in Scriptnode. This is how it's done:

HiseSnippet 1678.3oc6X0sTaaDEdEFQ.kzNIyzduFekyDJwlPRyjNYBXCl3TL3A4Roc5LYVjVi2hztJZWC1MStu859BzGsdQe.5aP6Y2UVRNlP.OjjdQMyHs+b946bzd9YoSB2mHD7Dj0RcGESPV2x1aDS1uQeLkgZsIx5ysaiERRhqYo5ihwBAI.YYUZa0BVKMOR+6ueVcbHl4SxWBgNfS8I6Pinx7U6r92RCCahCHcoQEnds0a4yYM3g7A.dJYWEEi8OAeLYWrhr4rQVKrU.UxS7jXIQfrluNOXjWe9YLC8GPEziBIpI0PdffLK2jGFnPrZUTi9zvfNisaABYY2I2KTx3E9B61z.Z154diaq2vMmih9Cq4lDdkl.d0dWv6bfjUAHMuAR2w1yOgFKy2QgmaZ2hAeb5gA2dQnXnEM2CKY2fCTvjqDgOgzLAljwQkGUs5xtvi69MNN2+9c6SbYD4Y7jSbgODRvlorickvxGmfYCBwfs4.6HjtmhSbM5n4g0bepq9PyJGSjaLHfx8vQwgjLjVorgTWf1xFcsMQpEbOZBHMMSv3PhqHjKc6kvizamBmTkp26o45MSeMANqTMWxifSPtBMHbCoBYAPaVMBGKTRROIQIGyv133c.5qjKJLKvMlGqLdhFR97ni3GwGVPlMTKUmOT4HF6sAQBKGyYvjJkynPY9YSVQPf8nRRjn7xEP1J+LmxpT9mXkuqAH6vwAZkmQiCkERYf+a.yWR4LWUfSpXUPHgGVwer9WFPY3.xccdsyRJe3Jgf7z9rxu9ve3GexSxL92T18dtY7oLhV.55RFBtD.JuAPy60.UVUJDZfCCOBhgqLM5TFVAvuKWR1iUQCQm23391a0q24tWpvfugm61p7KIWDiUXChNhjTzAoHDB5lLRdgKWjruw2TfPNqEiJ2KljN+hSEgRctpL.oHDHUpi+ucZ7+XGIhFnB+y7qHsIjmM8wqi9tVahk3wBCjKnqXRhjpLIqMImB4lMIWVxdSh3DIOVSa5WUvrujpdHjD0ZQKDZjZvK.sGg0qcOXn97MZtirrqSfJIs4ADm5g7yF400odBjjwi7Jm5Bxq7h3bYem5CRBbZ38U6xoBR1fZYiVMazCxFslZTmAgozoGsZ1HMcd3yzufnFmFIvIg9J.zP.er7OQMZPbCHCILZyl0zOWEdtUD.Qg.d6ISfrgqlMRTyY6D7ojPfpsSHXI7947cFFE57hgFlZSj3Z5mqpe9.8y0zOenydGuOVkqrKLxKbj9cPO3kFyFk3r+Na5rO9TXUu96SDNdmQE8c5xSjZuy2yOau9vCmCi8HvW5oKa.Er3AlT2EqhoJcmtADPLQoCU4AlfJGUrz9UnzV0Krz1kEh2wtCU52+7w3bmCFgi4eHvXZCAel8V85Q7k4.bd6lGNqU+u7pew2QWY2RWVGlQRpcczSV7ktmLqRWjYV8Jzjy7eB56554v4+G+7e43mI5d11neG6wcMlF9j2Q5DfX2AQYcTJTUvfhZnzlos9U67VHhSHw3DRWdmP7nJl9x1G.9xtGEpJnP+Exz8cDavUcEEU76iYLRnXVZOYgqoKZf1mOPB0YZigxMpJ1f86Ag59jFonS4ClS0YhYdU0b0gEOBKPO4efeoaVKygAaVa7l4M0f10zNu9aT5Xj0MTePtg8wfkHQaDBcFn5.gldpE9lnWqCObTbeNi5qVxPwXPtQDefpcECReNVzESCUGy8FHfNuB1i4ADqyBZU5.RhPK3aXWcE3O3X+tPKI.2Mw9fOcTGrruJ9webB1U7yNzNFlSbjA3dbBRiuAPWjt+I0UVKUnoKyQS0LHvaNyAwVhCT65iCQGX5fCrBkLMdICzLW0KBRAZvxDP8KK.0bR9T.waYmeQQzTtyDxJE1dVwmZKHVa33VaKDtVbFjfoEKfLbr.2BBjBfVu0rkdxrMkkZOFZZiGNwbTGbBNh.2VVI6ExlAiyYMO+YN64488jjXUtfhz4cB4LiyoHkJ+micGNjUVc7bJoitX0+mOaZ0iV+Ro9+32q9WOyb5VWy.MkU7dz8ZqOst+s0uZl9Ms2VeW.ECukn5tN5CuqWcCHSEwqpm+5P6KZ6AETvAehT9lD4.F4hTt3smTmyOIBqykOS2y7iRkmOF5HB6mveouofsJOwh5UfrVL8+1xkraql6N0EzgKICIqeou+jhZJFWcVY7AyJiqMqL9vYkwGMqL90yJiO98yn5FGaLPxiLch.gZc1xT9vZKFF5uRW6B8u.bB.apC

There's a post from a couple of years back that explains this in detail here.
